GOBLIN urukay carbon

Advertisement

loading
Need help?

Need help?

Do you have a question about the Goblin URUKAY CARBON and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SAB Heli Division Goblin URUKAY CARBON

Summary of Contents for SAB Heli Division Goblin URUKAY CARBON

  • Page 1 GOBLIN urukay carbon...
  • Page 2 Goblin URUKAY CARBON Manual Release 1.1 - November 2016 WORLD DISTRIBUTION www.goblin-helicopter.com For sales inquiries, please email: sales@goblin-helicopter.com For info inquiries, please email: support@goblin-helicopter.com Attention: If you are a consumer and have questions or need of assistance, please contact in a first time the Goblin retailer where you made the purchase EUROPEAN DISTRIBUTION www.sabitaly.it...
  • Page 3 It is extremely important that you take a moment to register your helicopter with us. This is the only way to ensure that you are properly informed about changes to your kit, such as upgrades, retrofits and other important developments. SAB Heli Division cannot be held responsible for issues arising with your model and will not provide support unless you register your serial number.
  • Page 4 SAB Heli Division to be defective In the event of a defect, this is the Purchaser’s exclusive remedy. Replacement decisions are at the sole discretion of SAB Heli Division. This warranty does not cover cosmetic damage or damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or modification of or to any part of the Product.
  • Page 5 Chapter 3, Components and Box ADDITIONAL COMPONENTS REQUIRED TOOLS, LUBRICANTS, ADHESIVES *Electric Motor: 400 - 560Kv *Generic pliers Maximum diameter 64mm, *Hexagonal driver, size 1.5,2,2.5,3,4mm Maximum height 72mm, *4mm T-Wrench Pinion shaft diameter 6/8mm *5.5mm Socket wrench (for M3 nuts) *8mm Hex fork wrench (for M5 nuts) *Speed controller: minimum 120A , suggest 160A *Medium threadlocker (eg.
  • Page 6 Chapter 4, Carbon Frame The manufacturing process of the carbon parts often leaves micro-burrs and sharp edges. We recommend de-burring the edges to minimize the 4-Carbon Frame risks of electrical wire cuts, etc. Very important in red line zone. Page 4...
  • Page 7 Chapter 4, Carbon Frame Battery / ESC Position It is possible to place the battery support in many positions. The two main positions are illustrated. ( Light Batteries < 1500-1600g ) ( Heavy Batteries > 1600-1700g ) Here is showed another position. It allow you to raise the center of gravity of the model. The three previous positions are in relation to the position "top"...
  • Page 8 Chapter 4, Carbon Frame Bag 1 Socket Head Cap Battery Tray Assembly Screw M2.5x8mm (HC020-S) Battery Tray Stop Battery Plate Flat Head Cap (H0002-S) (H0150-S) Screw M2.5x5mm (HC128-S) Frame Spacer (H0003-S) Note: Frame Spacer (H0003-S) Flat Head Cap Screw M2.5x5mm (HC128-S) ESC Support Flat Head Cap...
  • Page 9 Chapter 4, Carbon Frame Bag 1 Carbon Frame Assembly Left Main Frame Assembly Main Frame (H0824-S) Finishing Washer M2.5 (H0255-S) Socket Head Cap Screw M2.5x8mm (HC020-S) Socket Head Cap Finishing Screw M3x10mm Washer M3 (HC056-S) (H0007-S) Socket Head Cap Screw M3x10mm Finishing (HC056-S) Washer M3...
  • Page 10 Chapter 4, Carbon Frame Bag 2 Top ESC Support Assembly Frame Spacer Socket Head Cap Finishing (H0003-S) Screw M3x8mm Washer M3 (HC050-S) (H0007-S) Top ESC Support (H0450-S) ESC Carbon Top ESC Support Support Urukay Assembly (H0447-S) Finishing Washer M3 (H0007-S) Socket Head Cap Screw M3x8mm (HC050-S)
  • Page 11 Chapter 5, Transmission Assembly Bag 3 Flat Head Cap Screw M2.5x5mm Bearing 24x6mm (HC128-S) (HC426-S) Bearing Support Assembly (H0024-S) Socket Head Cap Socket Head Cap Screw M3x10mm Screw M3x10mm (HC056-S) (HC056-S) Servo Support (H0010-S) Column (H0018-S) Column (H0018-S) Bearing 19x5mm (HC422-S) Swash plate Anti-Rotation Guide...
  • Page 12 Chapter 5, Transmission Assembly Bag 4 Note: 60T Pulley Assembly (H0104-S) When you tighten the collar (H0121-S) on the main shaft, ensure there is no axial play. Push down the main shaft while pulling up the Bearing locking collar. Tighten the screw M4x22 at this time. 15x4mm (HC420-S) Front Tail Pulley Assembly...
  • Page 13 Chapter 5, Transmission Assembly Bag 5 Tail Belt Idler Assembly [H0834-S] Flanged Bearing 7x3mm (HC402-S) Bushing 4x8.6mm [H0060] Tail Belt Idler (H0834-S) Main Structure Assembly Belt Tensioner Arm Assembly [H0834-S] Button Head Cap Screw M3x4mm Socket Head Cap (HC038-S) Screw M3x20mm (HC080-S) Belt Tensioner Support [H0834-S]...
  • Page 14 Chapter 5, Transmission Assembly Bag 6 NOTE: Wire Direction Socket Head Cap Screw M3x8mm Where is your ESC ?. ( See page 19 ). (HC050-S) ESC top position >> FRONT. Flanged Bearing ESC bottom position >> LATERAL. Bearing Support (H0143-S) Lock 13x5mm H0143 after have locked the motor.
  • Page 15 Chapter 6,Main Rotor Bag 7 Uniball Arm Assembly ... x2 Radius Arm Assembly ... x2 Center Hub Assembly Flanged Bearing Flanged Bearing 2.5x 6x2.5mm 7x3mm Radius Arm eg: Microlube GL261 (HC400-S) (HC402-S) (H0132BM-S) Spindle (H0481-S) Uniball Radius Arm [H0205] Spacer Arm 2.5x 4x6.3mm Spacer Arm...
  • Page 16 Chapter 7, Assembling The Modules Bag 8 Swashplate Assemly Uniball M3 [HC062-S] Uniball M3 [H0422-S] (H0063-S) (H0065-S) [HC111-S] Head Screw M3x10mm [HC062-S] [HC212-S] (HC056-S) Socket Head Cap Socket Head Cap Screw M3x12mm Shoudered Screw M4x24mm (HC062-S) (HC111-S) Metrix Hex Socket Head Cap Nylon Nut M4 Screw M3x12mm (HC212-S)
  • Page 17 Chapter 8, Installation Of Swashplate Servos Bag 9 INSTALLATION OF SWASHPLATE SERVOS The linkage ball must be positioned between 17-19 mm out on the servo arm (Figure 1), recommended servo arm SAB p/n [HA050/HA051]. The 120° placement of the servos inside Goblin means the arms are difficult to access. For this reason it is advisable to ensure alignment of the servo arms (and sub trim set) before installation of the servos in the model.
  • Page 18 Chapter 8, Installation Of Swashplate Servos Bag 9 The wire for the front servo must be positioned here. Use zip ties. Head HF3C Version Preliminary Setup Linkage Rod A Assembly ... x2 Adjust the linkage as shown. The linkage Rod A has thead right/left. Turning, you can change the tracking without disconnecting the Approx 68mm plastic ball link.
  • Page 19 Chapter 9, Installation Of The Motor / Tail Servo Bag 9 TRANSMISSION SETUP It is important to choose the right reduction ratio to maximize efficiency based on your required flight performance. The Goblin has many possible reduction ratios at your disposal. It is possible to optimize any motor and battery combination. It is recommended to use wiring and connectors appropriate for the currents generated in a helicopter of this class.
  • Page 20 Chapter 9, Installation Of The Motor MOTOR BELT TENSION *Assemble the motor and pinion to its mounting plate. *Fit the motor assembly into position. *Compress the springs by pushing the motor toward the main shaft. *At maximum compression, temporarily tighten one of the slide screws. *With the minimum centre distance it is easy to install the belt.
  • Page 21 Chapter 10, Installation Of The ESC DE-BURR THE SIDE FRAMES We recommend de-burring the edges of the carbon parts in areas where electrical wires run. ( See page 4) ESC INSTALLATION Figure 1: shows the installation of the Kosmik ESC Figure 2: Shows the wiring which connects the receiver and ESC.
  • Page 22 Chapter 11, Installation Of Flybarless Unit and RX Bag 9 FLYBARLESS CONTROL UNIT AND RX INSTALLATION Figures 1 shows an example of installation of the flybarless control unit. You can use short spacer H0727 ( Figure 2 ). You can use long spacer H0043 ( Figure 3 ). This is typical if you want to put RX satellite under the control unit. Socket Head Cap Screw M3x6mm (HC044-S)
  • Page 23 Chapter 12, Tail System Bag 10 Tail Rotor Hub Assembly Tail Pitch Slider Assembly Tail Pitch Slider 01 [H0055BM] Flanged Bearing 12x3.5mm eg: Microlube GL261 (HC418-S) Spindle Shaft (H0329-S) Oring Spacer (HC335-S) 8.1x 9.2x3.2mm [H0029] Tail Shaft (H0325-S) Tail Pitch Slider 02 (H0407-S) Tail Pitch Slider 03 [H0054]...
  • Page 24 Chapter 12, Tail System Bag 11, Bag 12 Bell Crank Lever Assembly Tail Side Plate Assembly Bell Crank Base Flanged Bearing Socket Head Cap (H0058BM-S) 13x5mm Screw M2.5x8mm (HC414-S) (HC020-S) Washer 4x0.5mm (HC176-S) CF Tail Plate Flanged Bearing (H0494-S) 7x3mm Tail Pin (HC402-S) (H0264-S)
  • Page 25 Chapter 12, Tail System Bag 13 Tail Boom Assembly Red Tail Fin (H0823-S) Carbon Fiber Tail Boom Silver/Carbon You have to glue the tail fin. (H0724-S) Use Silicon (You can replace). Carbon Fiber Tail Boom Ennio Graber Edition Use Super Glue (You can't replace). (H0822-S) DETAIL A Attaching H0082-S to the boom:...
  • Page 26 Chapter 12, Tail System Bag 14 Finishing Socket Head Cap Tail Boom Washer M3 Screw M3x12mm Assembly (H0007-S) (HC062-S) Finishing Washer M3 Tail System Assembly (H0007-S) Socket Head Cap Screw M3x12mm (HC062-S) Note: Before put plastic ball in threaded rod, please wait 12 hours after bonding Threaded Rod M2.5x40mm Threaded Rod M2.5x40mm (HC242-S)
  • Page 27 Chapter 12, Tail System Bag 15 Note: * Install H0394 to the boom. * Insert carbon rod through the boom making sure it is inserted through H0394. * Install H0395 making sure to reduce slop (side play) on the carbon rod. DETAIL A DETAIL B Carbon Rod...
  • Page 28 Chapter 13, Installation Of The Boom, Canopy Bag 16 BOOM ASSEMBLY *Insert the tail boom assembly . *Lock the M8 nuts with the HA016 special tool supplied (Tray 2). *Firmly lock the lateral srews M3x12. Use Loctile for this screw and make sure you remain tight. *Assemble the H0038 carbon security plate .
  • Page 29 Chapter 13, Installation Of The Boom, Canopy TAIL BELT TENSION *Check the proper assembly of the tail boom. *Check that the aluminum part of the tube is against the M3 stop screw. *Loosen the tail group by loosening the 4 M3 screws. *Install the belt onto the pulley, taking care to respect the direction of rotation (figure 1).
  • Page 30 Chapter 14, Battery Bag 17 BATTERIES The battery tray system in the Goblin URUKAY is simple, but very effective. The battery should be attached to the tray (Part H0149) with heat shrink, tape or velcro. You can optionally use the battery protection tray (Part H0151) see Fig. 1, 2. Before permanently mounting the batteries onto the battery tray, check the ideal position for the best center of gravity.
  • Page 31 Chapter 15, In Flight Bag 18 OPERATIONS BEFORE FLIGHT *Set up the remote control and the flybarless system with utmost care. *It is advisable to test the correct settings of the remote and flybarless system without main blades and tail blades fitted. *Check that all wiring is isolated from the carbon/aluminum parts.
  • Page 32 Chapter 16, Maintenance MAINTENANCE *On the Goblin, areas to look for wear include: Motor belt Tail belt Damper Main gear and pinion The lifespan of these components varies according to the type of flying. On average it is recommended to replace these special parts every 100 flights.
  • Page 33 Chapter 17, Exploded view, Carbon Frame Main Frame Main Frame Name Specification Quantity Name Specification Quantity H0495 Tail Servo Support Aluminum H0002 Battery Tray Carbon Fiber Landing Gear Support H0496 Aluminum H0003 Frame Spacers Aluminum H0497 Wire Supports Carbon Fiber H0007 Finishing Washers M3 Aluminum...
  • Page 34 Chapter 17, Exploded view, Transmission Assembly Support single-unit FBL TRANSMISSION ASSEMBLY Name Specification Quantity TRANSMISSION ASSEMBLY Name Specification Quantity H0007 Finishing Washers M3 Aluminum HC092 Socket Head Cap Shoudered m3 x 50mm H0009 Main Structure Aluminum HC098 H0010 Servo Support Aluminum Button Head Cap Screws M4 x 8mm...
  • Page 35 Chapter 17, Exploded view, Head System Servo Assembly 1, 2, 3 Head System Code Name Specification Quantity Head System Code Name Specification Quantity H0031 Uniball Spacers Aluminum HC020 Head Cap Screws M2.5x10mm H0063 Uniballs M3x4 5 H18 HC026 Head Cap Screws M2.5x12mm H0064 Uniballs...
  • Page 36 Chapter 17, Exploded view, Tail System TAIL SYSTEM TAIL SYSTEM Name Specification Quantity Name Specification Quantity H0007 Finishing Washer M3 Aluminum H0494 Carbon Tail Side Plate Carbon Fiber H0029 Spacer 8.1 x 9.2 x 3.2mm H0822 Tail Boom Ennio Edition H0041 Locking Element Tails Carbon Fiber...
  • Page 37 Chapter 18, Spare Parts Battery Tray Frame Spacer Finishing Washer M3 Canopy Positioner Main Structure [H0002-S] [H0003-S] [H0007-S] [H0008-S] [H0009-S] - 1 x CF Battery Tray. - 6 x Flat Head Cap Screws M2.5x5mm. - 3 x Frame Spacers. - 10 x Finishing Washers . - 2 x Canopy Positioner .
  • Page 38 Chapter 18, Spare Parts Boom Spacer Washer Front Tail Pulley One Way Pulley Bush One Way 3.1x 12x1.8mm [H0082-S] [H0101-S] [H0104-S] [H0110-S] [H0078-S] - 2 x Brass Bushing. - 1 x Front Tail Pulley. - 2 x Radial Bearings - 1 x Socket Head 15x4mm.
  • Page 39 Chapter 18, Spare Parts 25T Tail Pulley Steel Pinion Z19 Secondary Shaft Aluminum Blade Spacer Plastic Radius Arm [H0155-S] [H0156-S] [H0157-S] [H0158-S] [H0205-S] - 1 x Secondary Shaft M3. - 1 x Head Cap Shouldered - 1 x Steel Pinion Z19. M2.5x19mm.
  • Page 40 Chapter 18, Spare Parts Spindle Damper Damper Damper Damper [H0481-S] [H0482-60-S] [H0482-70-S] [H0482-80-S] [H0482-90-S] - 1 x Spindle. - 2 x Head Cap Screw M6x10. - 2 x Washer Ø6xØ14x1.5. - 1 x Damper 60 Shore. - 1 x Damper 70 Shore. - 1 x Damper 80 Shore.
  • Page 41 Chapter 18, Spare Parts [HC002-S] [HC004-S] [HC008-S] [HC010-S] [HC018-S] [HC020-S] - 8 x Socket Head Cap - 8 x Socket Head Cap - 8 x Socket Head Cap - 8 x Socket Head Cap - 8 x Socket Head Cap - 8 x Socket Head Cap Screws M2x5mm.
  • Page 42 Chapter 18, Spare Parts [HC200-S] [HC206-S] [HC212-S] [HC218-S] [HC230-S] - 5 x Shims - 10 x Metric Hex Nylon - 10 x Metric Hex Nylon - 10 x Metric Hex Nylon - 5 x Metric Hex Nylon Nuts M2,5H3,5. Nuts M3H4. Nuts M4H5.
  • Page 43 SAB HELI DIVISION Black Polo Shirt SAB HELI DIVISION Black Hoodies [HM025-S-M-L-XL-XXL] [HM027-S-M-L-XL-XXL] [HM029-S-M-L-XL-XXL] - SAB HELI DIVISION New Black T-shirt. - SAB HELI DIVISION Black Polo Shirt. - SAB HELI DIVISION Black Hoodies. SAB HELI DIVISION Neck Strap SAB Transmitter Case...
