- Page 1 OE7701 & OE7702 Pasta Boiler USER, INSTALLATION AND SERVICING INSTRUCTIONS IS399 ECN3290...
-
Page 2: Customer Information
Details are available from your local distributor or direct from us. Used for the purposes for which it is intended, and with careful maintenance as outlined in this User Guide, your Lincat product will give you years of trouble free service. IMPORTANT INFORMATION Please read all of the safety and operating instructions carefully before using this product. -
Page 3: Table Of Contents
CONTENTS Contents Page Customer Information………………………………………………………. 2 Warnings and Precautions………………………………………………… 3 Technical Data……………………………………………………………….. 4 Commissioning………………………………………………………………. 5-6 User…………………………………………………………………………….. 7-11 Servicing ……………………………………………………………………… 12 Component Replacement ………………………………………….……… 12 Spare Parts List……………………………………………………………… 13 Fault Finding…………………………………………………………………. 13 Circuit Diagrams…………………………………………………………….. 14-15 Service Information…………………………………………….…………… 16 WARNINGS AND PRECAUTIONS It is mandatory that all appliances are installed, commissioned and serviced by a qualified and competent person as defined by the regulations in force in the country of installation. -
Page 4: Technical Data
TECHNICAL DATA Description 400 Wide 600 Wide Product Code OE7701 OE7702 Overall height (mm) 1050 1050 Height to hob (mm) Width (mm) Depth, excluding handles (mm) Tank dimensions - w x d (mm) 300 x 270 500 x 270 Legs adjustable within range (mm) 135 to 190 135 to 190 Weight (Kg) -
Page 5: Commissioning
COMMISSIONING PREPARATION Remove all packaging and protective coatings prior to installation. SITING The installer must ensure that all local regulations are met. • The appliance must be installed on a level floor in a suitable position that is well lit, and positioned so as to prevent accidental touching. - Page 6 C o n t ro l /T a p K n o b OPERATIONAL CHECK Although all Lincat units are functionally checked during manufacture, commissioning must include a functional check of all controls. Set the energy regulator to maximum and allow the water to heat up.
-
Page 7: User
USER INSTRUCTION FILLING THE TANK • Check that the drain tap is closed in the safe locked position (see “Cleaning the tanks”). • Fill the tank of the appliance to the level mark on the rear tank wall by turning the mains water supply tap on the control panel. - Page 8 • When the temperature reaches the selected set point, the element will cycle on and off to maintain the set temperature. Note: There is a range of 6 cycles on the control knob & a constant power position beyond the ‘6’ setting. •...
- Page 9 RESETTING THE LIMIT THERMOSTAT • Isolate the unit from the electrical supply. • Leave the unit for at least 20 minutes to cool before refilling to the indicated level with fresh water. • Reset the limit thermostat by manually depressing the button (refer to the drawing below for location).
- Page 10 SCALE The formation of scale within a hot water system is common and if left unchecked may cause problems to the functioning of the appliance. In hard water areas scale formation builds up quicker than in softer water areas therefore checks on scale formation need to be more frequent. It is advisable, in order to prevent injury, the appliance be isolated and allowed to cool before inspecting for scale deposits within the tank.
- Page 11 USING THE DRAIN TAP DRAIN TAP Depress Align squares, press to engage, turn to open and close. Turn to Open Turn to Open BASKET LOADS Overloading the basket reduces the appliance output of cooked product and will result in uneven cooking.
-
Page 12: Servicing
SERVICING ROUTINE SERVICE We recommend that all servicing, other than routine cleaning, be carried out by our authorised service agents. • Carry out a general check on the installation paying particular attention to the following:- Is the unit installed with the correct rating of cable. Is it connected to the supply via a suitable isolating switch. -
Page 13: Spare Parts List
SPARE PARTS LIST Part number Description OE7701 OE7702 BA102 Large basket BA109 1/2 basket BA110 1/3 basket X (2 off) X (3 off) BA104 1/6 basket X (6 off) X (9 off) CO111 Contactor CO166 Swirl inlet fitting CO167 ½” Stop valve CO168 Compact tee inlet EL208... -
Page 14: Circuit Diagrams
CIRCUIT DIAGRAMS OE7701 PRESSURE SWITCH PS05 B B B B TERMINAL BOX TE45 LIMIT 'STAT B B B B FRONT ELEMENT AMBER NEON GREEN NEON LIMIT 'STAT REAR ELEMENT FRONT ELEMENT REAR ELEMENT ENERGY EL208 EL208 REGULATOR EN10 CONTACTOR CO111 Note: Wire 12 from the contactor to the pressure switch is wired to the Normally Open terminal. - Page 15 OE7702 B B B B PRESSURE SWITCH PS05 B B B B B LIMIT 'STAT AMBER LEFT ELEMENT NEON B B B LIMIT 'STAT CENTRE ELEMENT GREEN NEON LIMIT 'STAT RIGHT ELEMENT B B B ENERGY REGULATOR EN10 Note: Wire 12 from the contactor to the pressure switch is wired to the Normally Open terminal. Terminal numbers may vary.
-
Page 16: Service Information
If possible please quote the product code of the part you require. Lincat reserve the right to carry out any work under warranty during normal working hours, i.e. Monday to Friday, 8.30 a.m. - 5.30 p.m.
