Installation, Operating and Servicing
Instructions
Opus 700 Electric Pasta Boiler
OE7701, OE7702
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 399 ECN 3607
Page 1 of 15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincat Opus 700
Summary of Contents for Lincat Opus 700
- Page 1 Installation, Operating and Servicing Instructions Opus 700 Electric Pasta Boiler OE7701, OE7702 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 399 ECN 3607 Page 1 of 15...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING Install this appliance on a level surface ensuring all vents are unobstructed. Any partitions, walls or furniture must be of non-combustible material. Minimum distances A 100mm B 1000mm – see Fig 1. Fig 1 Do not install adjacent to any appliance with an exposed flame, such as a gas range or chargrill. -
Page 5: Operating Instructions
Electrical connection This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Cable colours are as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. - Page 6 Before first use Ensure the water drain tap is closed. You will need to check down the drain inside the tank to confirm this, as the handle safety feature means that the handle can be fitted in any orientation (see Fig 5). Clean the tanks thoroughly with a warm mild detergent solution.
- Page 7 If the water control valve is accidently left open, there is an overflow trough in front of the main tank, which connects to the main drain. Never fill the tank whilst the elements are hot as this will damage the appliance. Fit the basket drainer (Fig 3) onto the support pins in the side of the tank.
- Page 8 Turn on the power supply at the isolating switch; the green neon will illuminate indicating power to the appliance. Rotate the control knob to the desired setting – the amber neon will illuminate indicating power to the element. There is a range of 1-6 settings, with constant power position beyond the ‘6’...
- Page 9 Safety thermostat resets A LH element B Centre element C RH element Fig 4 Draining the tank Isolate the appliance from the supply and allow the water to cool to a maximum of 55 Deg C. Open the drain tap (Fig 5) and allow the water to drain. Opening the water control valve will assist in swirling water around the tank to rinse away any debris.
-
Page 10: Cleaning
Align squares at A Depress to engage – turn to open and close Fig 5 CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials or cleaners containing chlorine. -
Page 11: Servicing, Maintenance And Component Replacement
- allow the appliance to cool before carrying out inspection for scale. De-scale regularly using an approved de-scaling compound such as can be supplied by Lincat (Code MS19). Do not use hydrochloric acid based de- scaling compounds on stainless steel. - Page 12 Check all components for correct operation and replace if necessary. Check the operation of the safety thermostats – see Fig 4 for their location. Component replacement Energy regulator Remove the control knob – do not lose the retaining clip. Remove the screws beneath the facia panel and drop the panel down. Remove the retaining screws of the regulator.
-
Page 13: Fault Finding
FAULT FINDING Appliance will not heat Is the green neon illuminated Check mains isolator and fuse Is the energy regulator turned Turn on the energy regulator Is the amber neon illuminated Check safety thermostat resets Is the contactor operating Change the contactor Check the element IS 399 ECN 3607... -
Page 14: Spare Parts List
SPARE PARTS LIST Part Number Description Used on BA102 Large basket OE7701 BA109 1/2 basket OE7702 BA110 1/3 basket OE7701 (2), OE7702 (3) BA104 1/6 basket OE7701 (6), OE7702 (9) CO166 Swirl inlet fitting ½” stop valve CO167 CO168 Compact tee inlet CO215 Contactor EL208... -
Page 15: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
