Teknion Beginning Work Table Installation Manual page 7

interpret
Installation Guides
Section: TABLES
Description: WORK TABLE BEGINNING. MIDDLE, FINISH WITH STRAIGHT AND ANGLED LEGS
REMOVE MOUNTING NUTS, SCREWS AND CLAMP FOR MID GABLE INSTALLATION
BB3
Clamp to be
removed and
repositioned to
Mid Gable Position
BB2 BB1
STEP 4: Remove Nuts and Screws as shown on Illustration. Save for future installation.
End Gable
Connection.
(To be Removed and
Repositioned to Mid Gable Position)
End Gable
Connection.
(To be Removed and
Repositioned to Mid Gable Position)
Do Not Remove
BB1
BB2
Mid Gable
Connection
Mid Gable
Connection
Date: Jan 2018 Page No: 7 of 19
INT_504a
BB3
