Model
EABS8-1500-4S
EABS8-1500-4Q
EABS12-1100-4S
EABS12-1100-10S
EABS12-1100-4Q
EABS17-800-4S
EABS17-800-10S
EABS17-800-4Q
EABS24-500-10S
EABS24-500-4Q
Download the latest version of this document at
http://www.desouttertools.com/info/6159925220_EN
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
Cordless Angle Nutrunner
Product Instructions
Part number
6151660870
6151660880
6151660890
6151660900
6151660910
6151660920
6151660930
6151660940
6151660950
6151660960
WARNING
Printed Matter No. 6159925220_EN
Issue No.
04
Date
08/2020
Page
1 / 28
Advertisement
Table of Contents
Related Manuals for Desoutter EABS8-1500-4S
Summary of Contents for Desoutter EABS8-1500-4S
- Page 1 Printed Matter No. 6159925220_EN Issue No. Date 08/2020 Page 1 / 28 Cordless Angle Nutrunner Product Instructions Model Part number EABS8-1500-4S 6151660870 EABS8-1500-4Q 6151660880 EABS12-1100-4S 6151660890 EABS12-1100-10S 6151660900 EABS12-1100-4Q 6151660910 EABS17-800-4S 6151660920 EABS17-800-10S 6151660930 EABS17-800-4Q 6151660940 EABS24-500-10S 6151660950 EABS24-500-4Q 6151660960 Download the latest version of this document at http://www.desouttertools.com/info/6159925220_EN...
-
Page 2: Table Of Contents
Table of Contents Product Information .......................... 4 General Information......................... 4 Warranty.......................... 4 Website .......................... 4 Information about spare parts .................... 4 Dimensioning ........................ 5 CAD files .......................... 6 Overview ............................ 6 General overview ......................... 6 Product description ...................... 7 Technical data........................ 7 Accessories.......................... 9 Default tool Ethernet configuration.................. 9 WI-FI settings ........................ 10 Installation............................ 12 Installation Instructions........................ 12 Changing the angle head orientation ................. 12 Inserting the battery pack.................... 13... - Page 3 Upgrading tool firmware ..................... 22 Troubleshooting .......................... 23 What if the warning signal lights up in red.................. 23 Low battery alarm.......................... 23 List of user infos related to the tools.................... 23 08/2020 3 / 28...
-
Page 4: Product Information
• The product warranty relies on the correct use, maintenance, and repair of the tool and its component parts. • Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Desoutter or their Certified Service Partners during the warranty period is not covered by the warranty. -
Page 5: Dimensioning
Product Information Dimensioning Model Output drive EABS8-1500-4S Sq. 1/4" EABS8-1500-4Q Hex 1/4" EABS12-1100-4S Sq. 1/4" EABS12-1100-10S Sq. 3/8" EABS12-1100-4Q Hex 1/4" EABS17-800-4S Sq. 1/4" EABS17-800-10S Sq. 3/8" EABS17-800-4Q Hex 1/4" EABS24-500-10S Sq. 3/8" EABS24-500-4Q Hex 1/4" Model ØA ØB ØC... -
Page 6: Cad Files
Overview General overview EABS tools are wireless angle-head nutrunners. They are hand-held by the operator and powered by a Desoutter battery pack. Psets and Assembly Processes can be set up with: • CVI3 Vision • CONNECT • CVI CONFIG Tightening reports, results and curves are collected by the system the tool is connected to. -
Page 7: Product Description
18 V or 36 V Power consumption 500 W Torque range (Nm) Model Min. / Nominal / Max. EABS8-1500-4S 1.5 / 7 / 8 EABS8-1500-4Q 1.5 / 7 / 8 EABS12-1100-4S 4 / 10 / 12 EABS12-1100-10S 4 / 10 / 12... - Page 8 3.69 / 10.33 / 12.54 EABS17-800-10S 3.69 / 10.33 / 12.54 EABS17-800-4Q 3.69 / 10.33 / 12.54 EABS24-500-10S 7.38 / 16.23 / 17.70 EABS24-500-4Q 7.38 / 16.23 / 17.70 Rated speed (rpm) Model EABS8-1500-4S 1500 EABS8-1500-4Q 1500 EABS12-1100-4S 1100 EABS12-1100-10S 1100 EABS12-1100-4Q 1100 EABS17-800-4S...
-
Page 9: Accessories
DTH battery (single) 6158133850 EABS back suspension 6158132960 EABS front suspension swiveling bail 6158134050 Default tool Ethernet configuration Item Desoutter default parameter Other possible values Allocation method for IP address Static Keep original IP address DHCP IP address 192.168.5.221 Refer to local settings... -
Page 10: Wi-Fi Settings
Product Information Item Desoutter default parameter Other possible values Subnet mask 255.255.255.0 Refer to local settings Gateway 127.0.0.1 Refer to local settings Communication port 7477 Refer to local settings WI-FI settings Item Desoutter default parameter Other possible values Network name (SSID) - Page 11 Product Information ETSI TELEC Channel America Europe Japan Worldwide 5 GHz authorized channel list per regulatory domain Radio ETSI TELEC Channel band North America Europe Japan Worldwide U-NII-1 U-NII-2 U-NII-2 Ext U-NII-3 08/2020 11 / 28...
-
Page 12: Installation
Installation Installation Installation Instructions Changing the angle head orientation See the instructions in the diagrams. The angle head is in its standard position. Use fixing clamps to unscrew the angle head in the clockwise direction. Disconnect the parts and locate the new position of the angle head. Re-mount the angle head. -
Page 13: Inserting The Battery Pack
Installation Use fixing clamps to tighten the angle head in the anticlockwise direction. Apply a torque of 50 Nm. The angle head is in its new position. Inserting the battery pack Insert the battery pack in front or behind the tool until a locking sound can be clearly heard. There is no ON/OFF switch: the tool is ready to operate as soon as a battery pack is mounted. -
Page 14: How To Connect The Tool To Cvimonitor
Click Select to select the tool. Installing the DTH battery (single) Installation on a table Installation on a rail Note above that an additional accessory (1) is required to hold the tool. This Desoutter accessory can be ordered as 6158114110. 14 / 28 08/2020... -
Page 15: Installing The Eabs Back Suspension
Installation Installing the EABS back suspension This accessory can only be mounted on a tool with a serial number starting from 19B63996. Installing the EABS front suspension swiveling bail 08/2020 15 / 28... -
Page 16: Operation
Operation Operation Configuration Instructions How to set up the tool in stand-alone working mode Changing the tool working mode will erase the Pset, the results and curves present in the tool memory. Launch CVIMONITOR. Click this icon. Click Tool working mode. Tick Standalone. -
Page 17: How To Change Network Parameters
Operation How to change network parameters Via CVIMONITOR and eDOCK Refer to chapter How to connect the tool to CVIMONITOR [Page 14]. Click this icon. Click this icon to display the current parameters of the tool. Change the parameters. Refer to chapters Default tool Ethernet configuration [Page 9] and WI-FI settings [Page 10]. Check that IP address, subnet mask and port number of the controller/hub are compatible. -
Page 18: How To Check The Battery Charge Level
Operation The white front light illuminates the area to tighten. Press the trigger to start the tool. How to check the battery charge level The battery is charged to 90-100%. The battery is charged to 75-90%. The battery is charged to 50-75%. The battery is charged to 25-50%. - Page 19 Operation The tool powers off after 30 minutes of inactivity. Long press the reverse button (1). Refer to "Power off" configurable with CVI CONFIG. Press the "Function" button (2). Unplug and plug the battery pack. 08/2020 19 / 28...
-
Page 20: Service
Service Service Tool identification with CVIMONITOR Click this icon. Click Tool identification. Go to the bottom of the screen and click Read tool. A green tick indicates the reading is successful. Tool test with CVIMONITOR Click this icon. Click Tool test. Click Start tool test. -
Page 21: Preventive Maintenance
Advanced tool maintenance with ACCESS KEY Launch CVIMONITOR. To activate the screens, you need to have an ACCESS KEY USB stick with the right profile (configured with the Desoutter CVIKEY software). If not, contact your CVIKEY manager for support. Motor align Click this icon. -
Page 22: Declaring Fixed Accessories
It is mandatory to calibrate the tool equipped with the fixed accessory before use. Upgrading tool firmware Click this icon. Click Upgrade tool firmware. Contact your Desoutter representative to get the last firmware version. Follow the instructions on screen. 22 / 28 08/2020... - Page 23 The red light is steady. The WI-FI board is not detected. Contact your Desoutter representative to get more information and support. Low battery alarm When the light on the right side illuminates in white, the battery pack must be reloaded.
- Page 24 2- Check the tool cable is not damaged. W212 Result not stored 1- It is not possible to store the tightening result in the system. 2- Contact your Desoutter representative for support. W216 Current high 1- Maximum current exceeded. 2- Contact your Desoutter representative for support.
- Page 25 2- Replace the battery pack or your configuration. E223 Drive init error 1- Software failure. 2- Restart the system. 3- If the problem occurs again, contact your Desoutter representative for support. E227 Motor stalled 1- Motor stalled (could be missing phase, wrong motor tune or power electronics failure) 2- Try once again.
- Page 28 Original instructions Founded in 1914 and headquartered in France, Desoutter Industrial Tools is a global leader in electric and pneumatic assembly tools serving a wide range of assembly and manufacturing operations, including Aerospace, Automotive, Light and Heavy Vehicles, Off-Road, General Industry.
