condair
He2
Evaporative Humidifier / Cooling System
InstallatIon and operatIng InstructIons

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Condair HE2

Summary of Contents for Condair HE2

  • Page 1 Evaporative Humidifier / Cooling System InstallatIon and operatIng InstructIons...

  • Page 3: Table Of Contents

    Separator Weight Installation HE2 MC3 / HE2 MC3 Plus Module Code Identification 3.1.1 HE2 MC3 / HE2 MC3 Plus Installation Overview 3.1.2 Step 1 - Position the Evaporative Module 3.1.3 Step 2 - Install Blanking Plates 3.1.4 Step 3 - Connect Feed Water Supply 3.1.5 Step 4 - Install Drain Pipework...

  • Page 4: General Information

    5. The HE2 system MUST be connected to a clean, potable mains water supply and it is recommended that the supply pipe work is chlorinated. It is the responsibility of the user to ensure that the water system com- plies with local regulations and bylaws, particularly those for the control of Legionella microbes (such as the HSE ACoP L8, The control of Legionella microbes in water systems).

  • Page 5: Correct Use

    Legionnaire’s disease). When designing or installing an air handling system that incorporates “OEM HE2”, appropriate micro-organisms and microbial control methods MUST be consid- ered and this should only be undertaken by suitably qualified persons. A risk assessment MUST also be undertaken in relation to control of micro-organisms and microbial growth, especially Legionnaires disease.

  • Page 6: Delivery And Storage

    1.10 Disposal You must observe local laws and regulations when disposing of your Condair HE2 at the end of its working life. Use personal protective equipment as recommended in the handling section above when handling the evaporative material. In addition, respiratory protection should be worn to avoid inhala- tion of dust or debris from the air flow which may have accumulated on the material.

  • Page 7: Inlet Water - Quality Guide

    It is possible to use high-quality, treated effluent for non-potable applications. The following gives guidance on reclaimed water quality that may be acceptable for use within the HE2. “Effluent treated water”, must be treated by an appropriate water treatment method and risk assessed to ensure it is safe and suitable for use in the unit.
  • Page 8 Note: Adding DISIFIN tablets or other disinfection chemicals will increase the conductivity in the tank. This should be taken into account on systems where a conductivity control system is in use. If you are in any doubt about the suitability of water quality please contact your Condair distributor who will be pleased to support you.

  • Page 9: Product Overview

    The water that doesn’t evaporate assists in washing the matrix material and flows into a stainless steel tank at the base of the unit before being re-circulated up onto the matrix again (except in the HE2 OEM Direct Feed version, in which the water passes directly to drain).

  • Page 10: He2 Overview

    A single electrical junction box, with pre-wired flying lead for connec- tion to the management system is included in the HE2 MC3 system to simplify installation. The HE2 MC3 Plus system has two electrical junc- tion boxes with pre-wired flying leads. Water flow and level in the HE2 MC3...

  • Page 11: Typical He2 Xl Evaporative Module Overview Module Specification

    Typical HE2 XL Evaporative Module Overview Module Specification Matrix depth (see coding expla- Matrix Distribution Cassette nation at the back Header of this manual) Dim A Width (See coding explanation at the back of this manual). 445mm Tank Re-circulating (18”)

  • Page 12: Module Specification

    3 Stage (2 Solenoid valves) 6 Stage (5 Solenoid valves) - HE2 MC3 Plus only 4 Stage (3 Solenoid valves) 7 Stage (6 Solenoid valves) - He2 MC3 Plus only Optional Hygiene Systems PureFlo Ag+ anti-microbial cartridge and 5 micron sediment filter...

  • Page 13: Typical He2 Oem Circulating Evaporative

    Typical HE2 OEM Circulating Evaporative Module Overview Module Specification Dim A Width Matrix depth (See coding explanation at (See coding expla- the back of this manual). nation at the back of this manual). Distribution Header Matrix Re-circulating Pump Tank 445mm (18”) Tank...

  • Page 14: Typical He2 Oem Direct Feed Evaporative

    Typical HE2 OEM Direct Feed Evaporative Module Overview Module Specification Dim A Width Matrix depth (See coding explanation at (See coding expla- the back of this manual). nation at the back of this manual). Distribution Header Matrix Tank 445mm (18”) Tank Caution: 482mm (19”)

  • Page 15: He2 Mc3 Plus Management System Overview

    HE2 MC3 Plus Management System Overview Key lock Power light Power Microprocessor Controller 3 way switch (On - Off - Drain) Additional wiring connections Cable entry for 10m flying lead supplied pre-wired to Evaporative Module Management System Specification Description Specification Dimensions 360mm (14") wide x 420mm (17") high x 140mm (6") deep...

  • Page 16: He2 Mc3 Management System Overview

    HE2 MC3 Management System Overview Key lock Power light Power Microprocessor Controller 3 way switch (On - Off - Drain) Additional wiring connections Cable entry for 10m flying lead supplied pre-wired to Evaporative Module Management System Specification Description Specification Dimensions 300mm (12") wide x 420mm (17") high x 140mm (6") deep...

  • Page 17: Installation

    Installation Installation HE2 MC3 / HE2 MC3 Plus 3.1.1 HE2 MC3 / HE2 MC3 Plus Installation Overview Model shown HE2 MC3 Step 1 - Positioning the Evaporative Module Step 2 - Install blanking plates Step 3 - Connect feed water supply...

  • Page 18: Step 1 - Position The Evaporative Module

    Installation should only take place after careful consideration of final position of the Evaporative module and management system and should be in accordance with AHU/duct-work installation diagram below. Always discuss the position of the module with your Condair representative! Caution: The system must be installed within a waterproof AHU section.

  • Page 19: Step 2 - Install Blanking Plates

    3.1.3 Step 2 - Install Blanking Plates Once the Evaporative Module has been positioned in the waterproof section of air handling unit, non- corrosive blanking plates (not supplied) must be installed to prevent air bypass around the Module in the AHU. Typical blanking plate arrangement shown below.

  • Page 20: Step 3 - Connect Feed Water Supply

    3.1.4 Step 3 - Connect Feed Water Supply A feed water supply with a minimum flow of 14 litres (3.7 gallons) (28 litres (7.4 gallons) for XL) per minute at a pressure of 2 bar (29 psi) should be connected to the 1/2” BSP female threaded connection of the filling hose.

  • Page 21: Step 4 - Install Drain Pipework

    AHU. Please note: HE2 XL Systems do not have a combined drain and overflow. The system is supplied with drain plumbing and a separate 32mm push fit elbow on the overflow. They should NOT be combined to ensure adequate flow rate.

  • Page 22: Step 5 - Position The Management System

    The Evaporative Module is supplied with one 10m (33’) 12-core electrical inter-connecting cable for connection to the Management System (See Stage 5 Electrical Installation for details). The HE2 MC3 Plus management system has two 12-core electrical inter-connecting cables.

  • Page 23: Step 6 - Connect Power Supply To Management System

    An electrical power isolator (not supplied) must be fitted within 1m (39”) of the Management System. This is essential for the purposes of maintenance and emergencies. Model shown HE2 MC3 The electrical power cable to Management System should be suitably rated for a 230V / 5 Amp in the EU or 110V / 10 Amp load in the US.

  • Page 24: Step 7 - Connect He2 Module

    3.1.8 Step 7 - Connect Module HE2 MC3 The evaporative module is connected to the HE2 MC3 control panel by a 12 core flying lead which is supplied pre-wired to the evaporative module. Once the evaporative module and HE2 MC3 control panel are installed, the cable should be cut to a suitable length for installation and wired as shown.
  • Page 25 HE2 MC3 Plus HE2 MC3 Plus evaporative module is connected to the HE2 MC3 Plus control panel by two 12 core flying leads which are supplied pre-wired to the evaporative module. The first evaporative cable should be installed as instructed on the previous page. The second 12 core flying...

  • Page 26: Step 8 - Connect He2 Controls

    3.1.9 Step 8 - Connect Controls HE2 MC3 Controls Wiring Controls Interlocks are connected to terminals 12-15 and provide a method of switching the unit on or off, or overriding the normal operation of the HE2. The interlocks are supplied pre-wired with a link as standard.

  • Page 27: Step 9 - Connect He2 Controls

    Contact Humidifier Running Humidifier Running Terminals 23-25 (on the HE2 MC3 Plus management system only) are used to provide a humidifier running output, e.g. to indi- cate to a BMS system that the system is running. A nor- mally Open (N/O) contact, (i.e. one which will close in the event...

  • Page 28: He2 Oem Circulating Installation

    Legionnaire’s disease). When designing or installing an air handling system that incor- porates an “OEM HE2”, appropriate micro-organisms and microbial control methods MUST be considered and this should only be undertaken by suitably qualified persons. A risk assess- ment MUST also be undertaken in relation to control of micro-organisms and microbial growth, especially Legionnaires disease.

  • Page 29: Step 1 - Position The Evaporative Module

    AHU/duct-work installation diagram below. Always discuss the position of the module with your Condair representative! The following points must be considered The AHU / duct-work floor must be designed with a loading capacity capable of supporting the humidifier’s weight when wet, as the largest unit will weigh 461kg (1016 lb) when in operation - see back of this manual for weights and measures.

  • Page 30: Step 2 - Install Blanking Plates

    3.2.3 Step 2 - Install Blanking Plates Once the Evaporative Module has been positioned in the waterproof section of air handling unit, non- corrosive blanking plates (not supplied) must be installed to prevent air bypass around the Module in the AHU. Typical blanking plate arrangement shown below.

  • Page 31: Step 3 - Connect Feed Water Supply

    3.2.4 Step 3 - Connect Feed Water Supply A feed water supply with a minimum flow of 14 litres (3.7 gallons) (28 litres (7.4 gallons) for XL) per minute at a pressure of 2 bar (29 psi) should be connected to the 1/2” BSP female threaded connection of the filling hose.

  • Page 32: Step 4 - Install Drain Pipework

    AHU. Please note: HE2 XL Systems do not have a combined drain and overflow. The system is supplied with drain plumbing and a separate 32mm push fit elbow on the overflow. They should NOT be combined to ensure adequate flow rate.

  • Page 33: He2 Oem Circulating - Requirements

    3.2.6 HE2 OEM Circulating - Requirements To ensure hygiene of the HE2 OEM Circulating Humidifier and to comply with applicable VDI stand- ards, the following requirements should be met: 1. A double check valve (DCV) must be fitted on the mains water inlet, to protect contamination of the mains water supply.

  • Page 34: He2 Oem Circulating Product Options

    3.2.7 HE2 OEM Circulating Product Options HE2 "OEM Circulating" Example shown: HE2-B22 (AS SUPPLIED) HEOEMCIRCKIT 1: HEOEMCIRCKIT 2: Drain Kit Level Control Kit Jubilee clips x 2 Motorised drain valve Overflow hose 28 mm push fit drain assembly (including a conecentration bleed-off connection point).

  • Page 35: He2 Oem Direct Feed Installation

    Legionnaire’s disease). When designing or installing an air handling system that incor- porates an “OEM HE2”, appropriate micro-organisms and microbial control methods MUST be considered and this should only be undertaken by suitably qualified persons. A risk assess- ment MUST also be undertaken in relation to control of micro-organisms and microbial growth, especially Legionnaires disease.

  • Page 36: Step 1 - Position The Evaporative Module

    AHU/duct-work installation diagram below. Always discuss the position of the module with your Condair representative! The following points must be considered 1. The AHU / duct-work floor must be designed with a loading capacity capable of supporting the humidifier’s weight when wet, as the largest unit will weigh 461kg (1016 lb) when in operation - see back of this man- ual for weights and measures.

  • Page 37: Step 2 - Install Blanking Plates

    3.3.3 Step 2 - Install Blanking Plates Once the Evaporative Module has been positioned in the waterproof section of air handling unit, non- corrosive blanking plates (not supplied) must be installed to prevent air bypass around the Module in the AHU. Typical blanking plate arrangement shown below.

  • Page 38: Step 3 - Connect The Feed Water Supply

    Legionnaire’s disease). When designing or installing an air handling system that incor- porates an “OEM HE2”, appropriate micro-organisms and microbial control methods MUST be considered and this should only be undertaken by suitably qualified persons. A risk assess- ment MUST also be undertaken in relation to control of micro-organisms and microbial growth, especially Legionnaires disease.

  • Page 39: Step 4 - Install Drain Pipework

    AHU. Please note: HE2 XL Systems do not have a combined drain and overflow. The system is supplied with drain plumbing and a separate 32mm push fit elbow on the overflow. They should NOT be combined to ensure adequate flow rate.

  • Page 40: He2 Oem Direct Feed - Requirements

    3.3.6 HE2 OEM Direct Feed - Requirements To ensure good hygiene of the HE2 OEM Direct Feed Humidifier and to comply with applicable VDI standards, the following requirements should be met: 1. A double check valve (DCV) must be fitted on the mains water inlet, to protect contamination of the mains water supply.

  • Page 41: He2 Oem Direct Feed Product Options

    3.3.7 HE2 OEM Direct Feed Product Options HE2 "OEM Direct Feed" Example shown: HE2-B22 (AS SUPPLIED) HEOEMDIRECTKIT 1: HEOEMDIRECTKIT 2: HEOEMDIRECTKIT 3: Drain Kit Inlet Valve Kit Automatic Drain Kit 28 mm push fit drain assembly Inlet solenoid 1 x Drain Solenoid...

  • Page 42: Commissioning

    If you are unsure of the quality of your water please consult your Condair distributor for advice.
  • Page 43 Programming the Controller controller is pre-set to the most commonly used parameters. However, each application is dif- ferent and may require parameters to be adjusted. The following section shows the default settings and the method used to adjust them. 1. Validate Temperature and Air Flow. Measure the air volumes and the air conditions, check this against the design data.
  • Page 44 8. Inlet Duration. Once the tank has fullly drained, allow the tank to refill. Time how long it takes to fill until the low level float switches. This will give you the “Inlet Fault Delay”. System Code: Operating Capacity (ltrs) MAX Inlet Duration (mins) HE2-X1X HE2-X2X HE2-X3X HE2-X4X HE2-X5X...
  • Page 45 14. Dilution Cycle. The table below should be used as a guide when inputting the dilution cycle interval and duration. Measure the water supply TDS (ppm) and set the dilution cycle accordingly. The dilution cycle duration should be set according to the evaporative system width. Ensure that the TDS is monitored, and the interval is adjusted accordingly.

  • Page 46: Commissioning (Oem Circulating And Oem Direct Feed)

    The commissioning of the humidifier requires appropriately trained technical personnel. It is strongly recommended that a service technician of your Condair distributor commissions your system. Please pay attention to local regulations regarding working at heights and electrical work. Part of this commis- sioning process is a disinfection of water tank and matrix.
  • Page 47 Commissioning (OEM Circulating OEM Direct Feed) 1. Validate temperature and air flow. Measure the air volumes and the air conditions, check this against the design data. 2. Adjust the water level (Circulating ONLY). If the water level is incorrect, adjust the float on the water inlet valve to ensure that the water level in the tank is correct.

  • Page 48: Operating The He2 Microprocessor Controller

    Operating the HE2 Microprocessor Controller 4.3.1 The Microprocessor HE2 MC3 systems include a backlit microprocessor control system. User Interface: Principle of Navigation No. Name Discription Display The default display in the software is the status page. If no button is pressed for 10 mins, or the left arrow button is pressed, the software will return to this page.

  • Page 49: Programming The Controller

    Duration:____**_secs As part of the commissioning of a HE2, it is important to accurately time how INLET FAULT long it takes for the tank to fill from empty. This time should be entered as the Inlet Fault Delay.
  • Page 50 Width (mm) Matrix Wash Over Duration (mins) 1200 1500 1800 2100 2400 2700 3000 3300 3600 3900 Once the Duration has been changed, press the OK button, and change MATRIX WASH OVER Start to Yes. The will automatically start the Matrix Wash Over Cycle. The drain will remain permanently open for the duration of the cycle.
  • Page 51 DILUTION CYCLE of evaporative humidification or cooling leads to a build up of dissolved solids in the water tank. To control the level of dissolved solids in the tank, the HE2 Interval:____60_mins will operate a Dilution Cycle at preset intervals of operation. During the...
  • Page 52 Screen four allows setting the parameters for the Drain Cycle. To reduce the DRAIN CYCLE risk of bacterial growth caused by water stagnation in the system, the HE2 system carries out a Drain Cycle. The HE2 can be set to operate the Drain Start Time: 00:01 Cycle at a preset time of day (“Time Mode”), or after a preset period of non-...
  • Page 53 ~10secs will reset the “Due In” counter and clear a fault if applicable. Step 11 - Date, Time and Day The date, time and day are preset in the HE2 system and backed up with a DATE TIME AND DAY battery. The system will also automatically adjust for daytime saving. However,...

  • Page 54: Status Page

    The second line shows the relative humidity and the temperature of the area Setpoint: 60 % rH under control. If an external control signal is used to control the HE2, the second line will show the signal value in percentage or it will be blank if ON/ OFF mode has been selected.

  • Page 55: Alarms And Fault Modes

    4.3.5 Alarms and Fault Modes The following screens will be seen on the microprocessor display of the HE2 MC3 when faults occur. controller has an integrated fault diagnostic system and will indicate any faults on the display. All faults and alarms will be active as long as the cause is present. As soon as the cause is removed the faults will be cleared and the controller will return to normal operation.
  • Page 56 Service Due system requires regular servicing. When a service will soon be HE2 ON required, the microprocessor will display “Service Due in *** Hrs”. When the 56 % rH @ 25C service is due, “Service Due” will be displayed on the microprocessor and the Service Due common fault output will activate.

  • Page 57: Wiring Diagrams

    Wiring diagrams 4.4.1 HE2 MC3 Wiring Diagram Agnd 71 72 E L N E 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 INCOMING EXTERNAL SAFETY EXTERNAL...

  • Page 58: He2 Mc3 Plus Wiring Diagram

    4.4.2 HE2 MC3 Plus Wiring Diagram Black Brown Blue Grey Orange Pink Violet White Yellow/Black WARNING: Mains Voltage. Isolate unit before removing cover. Terminals E - 7 on both Evaporative Module Cables = Live Mains Voltage Terminals 8 - 11 on both Evaporative Module Cables = Low Voltage (24Vdc)

  • Page 59: Maintenance

    20°C, the should be cleaned and disinfected. Refer to the cleaning, disinfection and descaling instructions in this manual. Contact Condair distributor for advice on water sampling and analysis, disinfection of systems, service and maintenance.

  • Page 60: He2 Mc3 & Oem Maintenance Guide

    HE2 MC3 & OEM Maintenance Guide Please note that the information given below is only to act as a guide and the frequency of maintenance may depend upon the unit’s age, usage and water quality. Correct maintenance is vital to ensure optimum output and reliability.

  • Page 61: He2 Routine Water Sampling And Testing

    In the event that the humidifier pipework contains any residual water or has remained damp, and the temperature exceeded 20°C (68°F), the should be chlorinated using 50 ppm chlorine solution for 1 hour. Contact Condair distributor for advice on water sampling and analysis, disinfection of systems, service and maintenance.

  • Page 62: Cleaning And Disinfection

    Additional procedures will be required for supply water system pipe-work or water treatment systems prior to the humidifier. Condair Ltd. recommends that routine disinfection should take place in the following situations: •...

  • Page 63: Cleaning And Disinfection Method Statement

    Check for and complete maintenance requirements as per manufacturers instructions. • Always leave work area clean, dry and tidy. Step 8 - Recommission the system • Refer to the commissioning section of this manual. If in doubt always contact your Condair distributor.

  • Page 64: He2 Mc3 Frequently Asked Questions

    The run hours have exceeded the service counter. • Service to be completed as explained in the 'maintenance' section of the manual. • Contact your Condair distributor to arrange a service visit. • Reset service counters. Refer to the commissioning section of the manual.

  • Page 65: Detailed Problems

    • The air velocity or flow might be uneven across the face area of the system. Fit a perforated plate before the HE2. • The junction cover may be incorrectly fitted. Check the junction cover bracket is correctly fitted as shown.
  • Page 66 The system is not reaching setpoint, or has loss of performance. What should I check? • The humidifier cassettes are blocked or damaged. Check for damaged cassette(s) and replace if required. • The humidifier cassettes are incorrectly fitted. Check the humidifier has been fitted correctly by referring to assembly guide.

  • Page 67: Product Specification

    Product specification HE2 MC3 System Weight MODEL Efficiency A Efficiency A Efficiency B Efficiency B Efficiency C Efficiency C Dry Weight Wet Weight Dry Weight Wet Weight Dry Weight Wet Weight (kg / lb) (kg / lb) (kg / lb)
  • Page 68 Wet Weight (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) HE2-X61 85 / 187 153 / 337 90 / 198 164 / 362 164 / 362 174 / 384 HE2-X62...

  • Page 69: He2 Oem Circulating System Weight

    HE2 OEM Circulating System Weight MODEL Efficiency A Efficiency A Efficiency B Efficiency B Efficiency C Efficiency C Dry Weight Wet Weight Dry Weight Wet Weight Dry Weight Wet Weight (kg / lb) (kg / lb) (kg / lb) (kg / lb)
  • Page 70 Wet Weight (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) HE2-X61 73 / 161 141 / 311 78 / 172 152 / 335 83 / 183 162 / 357 HE2-X62...

  • Page 71: He2 Mc3 Direct Feed System Weight

    HE2 MC3 Direct Feed System Weight MODEL Efficiency A Efficiency A Efficiency B Efficiency B Efficiency C Efficiency C Dry Weight Wet Weight Dry Weight Wet Weight Dry Weight Wet Weight (kg / lb) (kg / lb) (kg / lb)
  • Page 72 Wet Weight (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) (kg / lb) HE2-X61 63 / 139 131 / 289 68 / 150 142 / 313 73 / 161 152 / 335 HE2-X62...

  • Page 73: He2 Separator Weight

    Separator Weight MODEL Dry Weight Wet Weight MODEL Dry Weight Wet Weight (kg / lb) (kg / lb) (kg / lb) (kg / lb) SEP-X11 2.1 / 4.6 3.1 / 6.8 SEP-X12 3.2 / 7.1 4.7 / 10.4 SEP-61 6.1 / 13.4 9.5 / 20.9 SEP-X13 3.9 / 8.6...

  • Page 74: He2 Module Code Identification

    = Product Identification B = 85% Efficient, 150mm (6”) Matrix Depth 9 = 3000mm (108”) Width 6 = 2000mm (79”) Height HE2 XL systems are not part of the standard range and are selected by your Condair representative on request.
  • Page 75 © condair ltd., printed in switzerland technical modifications reserved...
  • Page 76 40002-2 Manufacturer: condair ltd. Member of the Walter Meier group talstrasse 35-37, 8808 pfäffikon, switzerland ph. +41 55 416 61 11, Fax +41 55 416 62 62 info@condair.com, www.condair.com...
