OPL 2724 ZAPPER - QUICK START
(Slave mode)
After configuring the Bluetooth communication parameters using the
Wireless Reader Configuration Instructions, scan through steps 1-8 (as
appropriate) to complete the setup of your device
_ZZ_
1.
_ENAU_
2.
_PC05_
3.
_PD08_
4.
_AD01_
5.
_CA05_
6.
_bbd_
7.
_ZZ_
8.
_+-DSCO-+_

SET

(Places scanner in set mode)

ENABLE AUTO CONNECT

(Allows scanner to reconnect when returning in to range)
OPTIONAL

ENABLE TRIGGER CONNECT (5 SECS)

(Press and hold trigger for 5 seconds for a manual connection)

ENABLE TRIGGER DISCONNECT (8 SECS)

(Press and hold for 8 seconds for manual disconnection)

POWER SAVE MODE

(Scanner will disconnect if idle for 10 minutes)

AUTO RECONNECT (5 MINS)

(Scanner will attempt to reconnect for 5 minutes)
Only if step 2 selected

TRIGGER TO MAKE CONNECTABLE

END

SCAN TO MAKE DEVICE DISCOVERABLE
