  • Page 1 eSelect M 1 Cl NORME DI INSTALLAZIONE, USO E MANUTENZIONE OPERATING INSTRUCTIONS AND MAINTENANCE UNI EN ISO 9001-2015...
  • Page 3 (IT) DIRETTIVA "RAEE" SUI RIFIUTI DI APPARECCHIATURE ELETTRICHE ED ELETTRONICHE, AGGIORNATA A L'ULTIMA EDIZIONE Il simbolo sotto riportato indica che il prodotto non può essere smaltito come normale rifiuto urbano. Le Apparecchiature Elettriche ed Elettroniche (AEE) possono contenere materiali nocivi per l'ambiente e la salute e pertanto devono essere oggetto di raccolta differenziata: smaltite quindi presso apposite discariche o riconsegnate al distributore a fronte dell'acquisto di una nuova, di tipo equivalente o facente le stesse funzioni.
  • Page 4 CERTIFICATE OF CONFORMITY ETATRON D.S. S.p.A. Head Office Via dei Ranuncoli, 53 – 00134 ROMA • ITALY Tel. +39 06 93 49 891 • Fax +39 06 93 43 924 C.C.I.A.A. 535990 - Trib. di Velletri 5170/85 • Cod. Fisc. 06632160583 P.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS W arni ngs ............................7 Sym bol s used i n the m anual .
  • Page 6 START-UP DELAY ..........................14 FLOW SENSOR functi on “Proxi m i ty Sensor”...

  • Page 7: W Arni Ngs

    W arni ngs Read the warnings below carefully. They provide important information regarding safe installation, use and maintenance. Store this manual with the utmost care for future reference. The device is built to a professional standard. Its durability and electrical and mechanical reliability will be more efficient if it is used properly and maintenance is carried out on a regular basis.

  • Page 8: Assem Bl Y Of The I Nstrum Ent

     If you decide to no longer use a device, it is recommended to make it inoperable by unplugging it from the mains.  Make sure it is switched off electrically (both polarities), disconnecting the conductors from the contact points of the mains by opening the omnipolar switch with at least 3 mm between the contacts.

  • Page 9: Di M Ensi Ons Of The I Nstrum Ent

    System settings Automatic Offsets the temperature via a PT100 probe temperature Remote control via external RS485 / ETHERNET module, Modbus protocol with ETATRON RS485/Ethernet SmartApp® Software. The operator connects the unit via a PC, a smartphone or a tablet. ENGLISH...

  • Page 10: Installation

    INSTALLATION the instrument away from heat sources in a dry place Install at a maximum room temperature of 40°C. Comply with standards in force in the different countries regarding electrical installation (Fig. 2). If the power cord does not have a plug, the device must be connected to the mains by means of an omnipolar disconnecting switch with at least 3 mm between the contacts.
  • Page 11 Fig. 3 – Connection diagram TERMINAL BOARD “A” Relay 1 Setpoint 1 CL CHLORINE ON-OFF / PWM output relay timed pulses 1. Relay 2 Setpoint 2 CL CHLORINE ON-OFF / PWM output relay timed pulses Relay 3 Auxiliary ON-OFF AUX output for remote equipment with Timer programming 2.

  • Page 12: Eselect M1 Ph(Rx)

    TERMINAL BOARD “F” NEW membrane Chlorine sensor Open Chlorine cell OLD membrane Chlorine sensor Not Connected Not Connected White Wire Red Wire Not Connected Brown Wire Grey Wire BLUE Wire Green Wire Black Wire Brown Wire Yellow Wire ESELECT M1 PH(RX) Control Panel The following picture shows the control panel with a description of the functions of the various keys.

  • Page 13: Delay Output Response Del Ay On Set Poi Nt

    Example with CL chlorine with range 2 Cl ppm: if the selected setpoint is 1 Cl ppm and hysteresis is set at 0.050 Cl ppm, the two activation values are 0.95 and 1.05 Cl ppm; within this range, the setpoint is OFF and outputs are blocked, outside this range the setpoint is ON (always according to Direct or Reverse mode).

  • Page 14: Start/ Stop Ti M Es

    ADVANTAGES: preventing excessive addition of chemical product not only according to the setpoint, but also cancelling any form of programming of the instrument’s setpoint. START/ STOP TI M ES The Timer in real time makes it possible to control through a timer the AUX outputs for each remote device, for the period selected in the program.

  • Page 15: Initial Display

    To go forward quickly, press and hold one of the ◄► buttons The software version is shown when the instrument is on the lower part of the display. ETATRON The software is subject to revisions without notice. Model eSelec M1 The instrument is prepared for measuring and is then ready to operate.

  • Page 16: Tem Perature Setti Ngs

    SETTINGS SETTINGS SETTINGS SETTINGS Chlorine Scale Chlorine Scale Chlorine Scale Chlorine Scale Cl 0-2 p p m Cl 0-20 ppm 0-20 Cl ppm CLC 0-10 C l ppm (Tot )  MENU BASE   MENU BASE   MENU BASE  ...

  • Page 17: Basic Programming Menu

    BASIC PROGRAMMING MENU These are all the steps included in the MENU SELECTION menu configuration with BASIC programming: *Selecting the C h l o r i n e S c a l e , Menu Selection Menu Selection S E T P O I N T 1 and C A L I B R A T I O N ◄...

  • Page 18: Calibration > Basic Menu

    Modular pulses, also known as PWM “pulse width modulation”, support a proportional mode on each ON-OFF MENU SETPOINT 1 -2 Mode setpoint, activating the corresponding pulses on the output relays based on the measured value and always relating to the previous selected settings. Proportion al ...

  • Page 19: Start/Stop Times > Basic Menu

    Press ESC to go back to MENU SELECTIONU or press ESC ESC to go back to MEASUREMENT DISPLAYA START/STOP TIMES > BASIC MENU Menu Selection The Timer in real-time programs the days and exact time of instrument operations. Start/S top times Start/Stop times Start/Stop times Monday...

  • Page 20: Menu Selection > Expert Programming Menu

    Settings DATA RESET: resets default factory settings. ONLY to be used when the parameters do not match or if there Reset are programming issues or when the operator wishes to restart from scratch. NOT to be overused as many resets may undermine the instrument’s efficiency. ...
  • Page 21 MENU SETPOINT 1 MENU SETPOINT 2 Metering Metering Setpoint 2 is set for operations in Direc t Reverse Reverse mode: the output is active Direct mode: the output is active  EXPERT MENU   EXPERT MENU  also the measured value is higher when the measured value is lower than the one selected in the setpoint, than the one selected in the...
  • Page 22 MENU SETPOINT 1 -2 MENU SETPOINT 1 -2 MENU SETPOINT 1 -2 MENU SETPOINT 1 -2 Hysteresis Hysteresis Hysteresis Hysteresis 0.005 Cl ppm 0.05 Cl ppm 0.05 Cl ppm CLC 0.05 C l ppm (Tot )  EXPERT MENU  ...

  • Page 23: Analogue 4-20Ma Outputs Function Selection > Expert Menu

    MENU SETPOINT 1-2 MENU SETPOINT 1-2 Priming Priming The priming function does not take into account the setpoint value to allow the metering pump to remain primed, the outputs are not active. OF F  EXPERT MENU   EXPERT MENU  Press ESC to go back to MENU SELECTION or press ESC to go back to the MEASUREMENT DISPLAY...

  • Page 24: 4-20M A1 / 4 -20M A2 Outputs Chlori Ne > M Etering Functi On On Setpoi Nt

    SETTING 4-20mA SETTING 4-20mA SETTING 4-20mA SETTING 4-20mA Alarm MAX Alarm MAX Alarm MAX Alarm MAX 2,000 Cl ppm 20.00 Cl ppm 20.00 Cl ppm CLC 10.00 Cl ppm *(Tot )  EXPERT MENU   EXPERT MENU   EXPERT MENU  ...

  • Page 25: Calibration > Expert Menu

    If the operator has selected Cl C 0-10 Cl ppm , the AUX1 output is suited for two functions: controlling an external device or, by selecting Cleaning one may program a system for automatic cell cleaning, ask ETATRON or dealer for a CLC cleaning KIT.

  • Page 26: Settings > Expert Menu

    AUX SETTINGS AUX SETTINGS Program the AUX mode. Mode Mode AUX1 may be used to control an external Device or for Cleaning Devi ce Cl eani ng  EXPERT MENU  the open Chlorine Cell for maintenance purposes.  EXPERT MENU  Press ESC to go back to MAIN MENU or press ESC ESC to go back to the CONTINUOUS MEASUREMENT display In the highlighted steps, enter and select the desired parameters, confirm the selection with OK/MENU.
  • Page 27 SETTINGS SETTINGS Flow Sensor: if there is no water flow in the probe socket (and possibly in Flow Sensor Flow Sensor the system), the flow sensor (proximity sensor), ENABLED, disables all outputs ensuring no chemical substance is added (DISABLED by default). Disabled Enabled ...

  • Page 28: Instrument Troubleshooting

    It is recommended to use voltage protections, check the earthing system and, when other equipment is connected in parallel, use a transducer. Furthermore, ETATRON D.S. recommends installing a UPS (genset) to assure continuity, thus ensuring no data are lost. A system that is set up without following the proper electrical design rules, without an earthing system, with frequent ON/OFF operations, might directly undermine the duration of the electric circuit.
  • Page 29 ESPANOL 3...
