Compliances And Specifications; Standards - Brainlab Buzz 2.0 System And Technical User Manual

COMPLIANCES AND SPECIFICATIONS

4 COMPLIANCES AND
SPECIFICATIONS
4.1

Standards

Certificates and Approvals
• IEC 60601-1:2005+A1:2012(3.1 Edition)
• ANSI/AAMI ES60601-1:2005/(R)2012
• CAN/CSA-C22.2 NO. 60601-1:14
Ingress Protection
Component
Display
Computer
NOTE: * The Ingress Protection depends on the Buzz Display installation. For more details,
please refer to the Buzz 2 Site Planning Manual, Installation Requirements.
Do not use in wet areas or locations where liquids could enter the system. If liquids have entered
the system, do not operate the device. Disconnect it from the mains power supply and contact
Brainlab support.
System and Technical User Guide Rev. 1.2 Buzz Ver. 2.0
Buzz Rating According to IEC 60529
Buzz On-Wall IP20
Buzz On-Wall with
IP21
silicone joint*
Buzz In-Wall IP20
Buzz In-Wall with
IP44
silicone joint*
All variants IP20
49
