Third-Party Connections
Specification
Supported Security Protocols
Wireless Data Rate
Transmit Power (max)
Receive Sensitivity
Antenna Characteristics
Channels
USB Connections
Only connect bus-powered (low-power or high-power) devices compliant to the USB 1.x, 2.0 or
3.0 specification or specifically released devices to Buzz. Bus-powered devices must not draw
more power than 500mA (USB 2.0) or 900mA (USB 3.0) according to the USB specification.
Do not connect self-powered USB devices to Buzz. Self-powered devices are USB devices that
are externally powered by a separate power supply. Otherwise the safety and effectiveness of the
equipment cannot be guaranteed.
40
Values
Disabled, WEP 64 & 128bit, WPA-PSK(TKIP),
WPA2-PSK(AES)
802.11b 11, 5.5, 2, 1 Mbps
802.11a/g 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n 65, 58.5, 42, 39, 26, 19.5, 13, 6.5
Mbps
802.11b 15 dBm (31.6 mW) 802.11g 12.6 dBm
(18.12 mW) 802.11a 17 dBm (50.1 mW)
802.11b
Rate 11 Mb/s: -86 dBm
Rate 1 Mb/s: -92 dBm
802.11g
Rate 54 Mb/s: -72 dBm
Rate 36 Mb/s: -78 dBm
Rate 18 Mb/s: -84 dBm
Rate 6 Mb/s: -89 dBm
802.11a
Rate 54 Mb/s: -74 dBm
Rate 36 Mb/s: -80 dBm
Rate 18 Mb/s: -86 dBm
Rate 6 Mb/s: -90 dBm
Two (2) U.FL coaxial connectors, 50 Ohms
Max gain @ 5 GHz = 5.5 dBi
Max gain @ 2.4 GHz = 4.1 dBi
US/Canada:
802.11a (36, 40, 44, 48, 52, 56, 60, 64, 100,
104, 108, 112, 116, 132, 136, 140, 149, 153,
157, 161, 165)
802.11b/g (1-11)
Europe:
802.11a (36, 40, 44, 48, 52, 56, 60, 64, 100,
104, 108, 112, 116, 120, 124, 128, 132, 136,
140)
802.11b/g (1-13)
Japan:
802.11a
36, 40, 44, 48 (Known as W52)
52, 56, 60, 64 (Known as W53)
100, 104, 108, 112, 116, 120, 124, 128, 132,
136, 140 (Known as W56)
802.11b/g (1-13)
China:
802.11a (149, 153, 157, 161, 165)
