To this Document
Symbols in figures
To visualize parts and actions steps, the following icons are used:
Icon
1
I
X
LH
RH
8
Explanation
Reference sign for part
Position of a part (e.g. move from pos. I to pos. II)
Dimensions (e.g. B = width, H = height, L = length)
Action step: Tighten screws with torque key with specified tightening torque
Direction of motion
Direction of travel
opened
closed
enlargement of display detail
Framings, dimension line, dimension line limitation, reference line for visible parts
or visible mounting material
Framings, dimension line, dimension line limitation, reference line for covered
parts or covered mounting material
Laying routes
Left-hand machine side
Right-hand machine side
