ZyXEL Communications EX5501-B0 User Manual page 201

Figure 122 Interface Group Configuration
The following table describes the fields in this screen.
Table 76 Interface Group Configuration
LABEL DESCRIPTION
Group Name Enter a name to identify this group. You can enter up to 30 characters. You can use letters,
numbers, hyphens (-) and underscores (_). Spaces are not allowed.
WAN Interfaces Select the WAN interface this group uses. The group can have up to one ETH interface and one
used in the WWAN interface.
grouping
Select None to not add a WAN interface to this group.
Selected LAN Select one or more LAN interfaces (Ethernet LAN, HPNA or wireless LAN) in the Available LAN
Interfaces Interfaces list and use the left arrow to move them to the Selected LAN Interfaces list to add the
interfaces to this group.
Available LAN
Interfaces To remove a LAN or wireless LAN interface from the Selected LAN Interfaces, use the right-facing
arrow.
EX5501-B0 / AX7501-B0 / PX7501-B0 User's Guide
Chapter 15 Interface Grouping
201
