- Page 1 Turnout Autoadapt Brings the car seat out of the vehicle Turnout 2 and 4 Turnout 2E and 4E 3 Installationsmanual 11 Installation manual 19 Installationanleitung 27 Manuel d’installation 35 Manual de instalación 43 Manuale di installazione...
- Page 2 OPTIONS FOR TURNOUT Tilt function for the seat TILDA The seat base TILDA® tilts the entire seat backwards in three steps. Mounted between Turnout and the seat. Besides providing extra seat comfort, Tilda also makes transferring with a CARONY® through a low vehicle door opening much easier. To avoid conflict with the release lever of a manual Turnout, use a Tilda with the release lever placed on the opposite side.
-
Page 3: Prior To Installation
Holes Turnout upper plate: Glide rails, 2 alternative positions Carony rails Recaro rails Turnout lower plate: A = Holes for Turnout 2/2E (2-door vehicles) Motor B = Holes for Turnout 4/4E (4-door vehicles) Turnout E Turnout 2,4 adjustable cover swivel angle... - Page 4 Prepare the mounting bracket Mount following items on the mounting bracket before Slewing it is mounted inside the vehicle: bracket attachment • For all Turnout models: The seatbelt receptacle is mounted on the L-shaped attachment. Small Seatbelt, if it has been mounted on the original seat, protection (also possible seatbelt stretcher).
- Page 5 1. Place the high spacers on the mounting bracket, according to picture. TURNOUT 2E TURNOUT 2 2. Separate the upper plate (M6 nut) from the lower, to be able to reach the outer rear hole. Use the countersunk M8 screw.
-
Page 6: Electrical Installation
Electrical installation • For Turnout 4E and 2E: A. Mount the control box, for ex. behind the dashboard panel. B. Connect the main control box cabling to the motor cable and micro switch cable of Turnout. C. Install the safety switch, if this shall be installed, and connect the safety switch wire. If not used, the two conductors for this switch shall be connected to one another. - Page 7 Over-current protection and obstacle sensor The motor current is constantly being surveyed. When the current exceeds 18A, the movement immediately stops and reverses during 0.3 seconds. If something is obstructing the movement and causes the current to increase to more than 2.9A, the movement immediately stops and reverses during 0.3 seconds. Display for statement of condition and for fault indication The display is found inside the control box unit.
- Page 8 Adjust the maximum swivel angle • For Turnout 4E and 2E: Reducing the outer swivel angle: Contact (Turnout is delivered with a pre-set swivel feature of breaker 90°- 95°) 1. Start by loosening the outer adjustment screw. 2. Swivel out until desired maximum swivel angle is reached..
- Page 9 AUTOADAPT AB Åkerivägen 7 S-443 61 Stenkullen Sweden Phone: +46 302 254 00 E-mail: info@autoadapt.com...
