Metal Highsleeper Wardrobe
Assembly Instructions
Dimensions
Width - 185cm
Depth - 50.5cm
Height - 138cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
-
Please keep for future reference
151/5680
183/5030
Version 3 Date: 16/04/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Metal Highsleeper Wardrobe 151/5680
Summary of Contents for Argos Metal Highsleeper Wardrobe 151/5680
- Page 1 Width - 185cm Depth - 50.5cm Height - 138cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 3 Date: 16/04/14...
- Page 2 IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE • Argos Ltd. MK9 2 NW. • This product is intended for • Assembly of this product must children in the age 6 or above.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Below panels are for desk Top support x 2 (101.8 x 4.2cm) Table top...
- Page 4 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Below panels are for wardrobe Pilot holes for guidance only Right side panel (136.5 x 48.2cm)
-
Page 5: Tools Required
Components - Fittings Note: The quantities below are the correct amount to complete the assembly. in some cases mor may be supplied than are required. Rail support x 2 Handle x 1 50mm Screw x 46 30mm Dowel x 29 50mm Dowel x 4 39mm Locking pin x 6 (12 screws are included... - Page 6 Assembly Instructions (Desk) Step 1 Attaching top unit (4 pcs) the Top panel onto the Top support Finished front edge Groove underneath (4 pcs) onto the the Shelf support Finished front edge Groove underneath Finished Use Screws (6 pcs) front edge right left panels &...
- Page 7 Assembly Instructions (Desk) Step 1 - continued Place a small amount of Glue into the groove on Finished front surface the Shelf Carefully slide the Back panel into the unit. Place a small amount of Glue into the groove on the Top panel Use Screws (4 pcs) to...
- Page 8 Assembly Instructions (Desk) Step 2 Attaching bottom panel Use Screws (2 pcs) onto the Back support Insert Dowels (5pcs) into the Left side panel and Back support Use Screws (2 pcs) Right onto the unit. Insert Dowels (2pcs) into the Right side panel...
- Page 9 Assembly Instructions (Desk) Step 3 Attaching table top Screw Locking pins into the Table top Note: Insert Locking pins as far as shown. Do not over tighten. Place a small amount of Glue onto the joint’s surfaces. Use Screws (2 pcs) onto the unit.
- Page 10 Assembly Instructions (Desk) Step 3 - continued With help, carefully stand top unit upright. Warning: The top unit is heavy. Lift with care. Place a small amount of Glue onto the joint’s surfaces. Carefully locate the Table onto the unit. Insert 6 Locking nuts into the unit.
- Page 11 Assembly Instructions (Robe) Step 4 Attaching hinges and rail supports Door hinges ‘back plates’ onto the Right side panel Finished Rail support onto the front edge Right side panel Insert Dowels (6 pcs) into the Right and Left side panels &...
- Page 12 Assembly Instructions (Robe) Step 5 - continued Position Front panel Finished onto the Bottom front surface panel Finished front edge Use Screws (3 pcs) back edge onto the unit. Step 6 Attaching side panels back edge the Right and Left side back edge panels &...
- Page 13 Assembly Instructions (Robe) Step 7 Attaching top panel back edge the Top panel onto the unit. back edge Step 8 Fixing back panel Attach Back panels onto the unit using Nails back surface Important: The unit MUST be ‘square’ when the back is attached.
- Page 14 Assembly Instructions (Robe) Step 9 Attaching shelves With help, carefully stand robe upright. Warning: The robe is heavy. Lift with care. Note: Set the shelf supports to the desired height. lnsert Shelf supports into the unit. before inserting the shelves. Locate Clothes rail into the Rail supports...
-
Page 15: Hinge Adjustment
Assembly Instructions (Robe) Step 11 Hanging door With help, slot Door hinges onto ‘hinge plates’. Tighten screw shown to lock hinges in position. See ‘Hinge adjustment ’ in step 12 if the door need adjusting. Step 12 Hinge adjustment To move door up or down: loosen screws shown and move door to suit. - Page 16 Assembly Instructions (Robe) Step 12 - continued To move door left or right: loosen screw shown and move door to suit. Re-tighten screws. Door To move door in or out: loosen screw shown and move door to suit. Re-tighten screws. Door...
- Page 17 Assembly Instructions (Desk & Robe) Step 13 Fitting the unit Use Screws (5 pcs) to join the desk and robe together.
- Page 18 Screw Note: Before use allow the glue to dry for 24 hours and make sure the unit is secure. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
-
Page 19: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
