- Page 1 ALIGN 7477 ™ 3 BAY MEDIA CABINET WITH CONSOLE / MEDIA LEG INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Align Media Cabinet 7477 from BDI. Your cabinet has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your cabinet.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # DESCRIPTION Cabinet QUANTITY PART # PART # DESCRIPTION DESCRIPTION Base Rail End Plate QUANTITY QUANTITY PART # PART # PART # DESCRIPTION Media Leg DESCRIPTION Console Leg DESCRIPTION Back Panel QUANTITY QUANTITY QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 ASSEMBLY STEP 1. BUILD THE BASE Connect (A3) End Plates to (A2) Base Rails using PART/DESCRIPTION 8 (H1) Flathead Machine Screws. Tighten with (T1) Hex Wrench. T1-HEX WRENCH H1-FLATHEAD MACHINE SCREW 6 | BDIUSA.COM ALIGN 7477...
-
Page 7: Step 2. Attach The Legs
STEP 2. ATTACH THE LEGS ASSEMBLY Connect either (A4) Media or (A5) Console PART/DESCRIPTION Legs to the ends of the base assembly using 8 (H2) Machine Screws as shown. Start all screws before fully tightening the screws with T1-HEX WRENCH (T1) Hex Wrench. -
Page 8: Step 3. Attach The Base
Attach the base to the T1-HEX WRENCH (A1) Cabinet with 6 (H3) Flathead Screws using (T1) Hex Wrench. Do NOT fully tighten until all H3-FLATHEAD SCREW screws are started. MEDIA BASE CONSOLE BASE 8 | BDIUSA.COM ALIGN 7477... - Page 9 STEP 4. INSTALL BACK PANELS ASSEMBLY The 2 (A6) Back Panels are removable and can slide towards the middle. To install, put the top edge of the back panel into the top groove, then drop the bottom edge into the bottom groove. Your Align Media Cabinet comes with 2 (H4) KLEET Cord Wraps which can be used for cord management.
-
Page 10: Fine Tuning
(T2) Hex Leveler Wrench to attain a level, stable cabinet placement. Turning the leveler T2-HEX WRENCH clockwise will extend the leveler; turning it counter- clockwise will retract it. Leveling the cabinet will improve door alignment. down 10 | BDIUSA.COM ALIGN 7477... - Page 11 CENTER DRAWER / DRAWER ADJUSTMENT FINE TUNING The center pull out drawer on your Align media cabinet has 2 divider panels which may be removed if not in use. DRAWER ADJUSTMENT If needed the center drawer may be adjusted to align with the left and right doors. Two adjustment mechanisms are found on the underside of the drawer at the left and right front corners.
- Page 12 Door C & Door D here Door C Loosening SCREW 1 on this hinge will close the seam between Door C & Door D here Door A Door B Door C Door D 12 | BDIUSA.COM ALIGN 7477...
-
Page 13: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 14: Warranty
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. - Page 15 NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 15...
- Page 16 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Align & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2020, BDI | V.02.07.2020 Made in China.
