- Page 1 ALIGN 7473/79 ™ 4 BAY MEDIA CABINET WITH CONSOLE / MEDIA LEG INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 2 Congratulations on the purchase of your Align Media Cabinet 7473 / 7479 from BDI. Your cabinet has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your cabinet.
- Page 3 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
- Page 4 QUANTITY PART # PART # PART # DESCRIPTION DESCRIPTION DESCRIPTION Media Leg Console Leg Back Panel QUANTITY QUANTITY QUANTITY PART # PART # DESCRIPTION Small Adjustable Shelf DESCRIPTION Large Adjustable Shelf QUANTITY QUANTITY 4 | BDIUSA.COM ALIGN 7473 • 7479...
- Page 5 STEP 1. BUILD THE BASE ASSEMBLY Connect (A3) End Plates to (A2) Base Rails using PART/DESCRIPTION 8 (H1) Flathead Machine Screws. Tighten with (T1) Hex Wrench. T1-HEX WRENCH H1-FLATHEAD MACHINE SCREW NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
-
Page 6: Step 2. Attach The Legs
Legs to the ends of the base assembly using 8 (H2) Machine Screws as shown. Start all screws before fully tightening the screws with T1-HEX WRENCH (T1) Hex Wrench. H2-MACHINE SCREW MEDIA LEGS CONSOLE LEGS 6 | BDIUSA.COM ALIGN 7473 • 7479... -
Page 7: Step 3. Attach The Base
2 PERSON TASK STEP 3. ATTACH THE BASE ASSEMBLY Make sure cartons are still inside the (A1) Cabinet PART/DESCRIPTION QTY to keep the shelves in place. With help from another person, carefully position the (A1) Cabinet on its back as shown. Attach the base to the T1-HEX WRENCH (A1) Cabinet with 6 (H3) Flathead Screws using (T1) Hex Wrench. -
Page 8: Fine Tuning
(T2) Hex Leveler Wrench to attain a level, stable cabinet placement. Turning the leveler clockwise will extend the leveler; turning it counter-clockwise will retract it. Leveling the cabinet will improve door alignment. 8 | BDIUSA.COM ALIGN 7473 • 7479 down... - Page 9 ADJUST DOOR HINGES (IF NEEDED) FINE TUNING These steps are to be followed after you have unpacked and completed the simple assembly instructions for your console. Due to jostling in freight or perhaps an uneven floor, the doors on your cabinet may not appear to be in perfect alignment.
-
Page 10: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 11: Warranty
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. - Page 12 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Align & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2020, BDI | V.02.07.2020 Made in China.
