- Page 1 Installation • Operation • Care Design Studio ™ Decorative Drapery Hardware...
-
Page 2: Table Of Contents
CONTENTS GETTING STARTED Product View—Decorative Drapery Hardware Pleated Style Side Panel or Drapery............1 Product View—Decorative Drapery Hardware Grommet Side Panels ..................2 Tools and Fasteners Needed ...............3 INSTALLATION Install the Brackets — Wall Mount ............4 Install the Brackets — Ceiling Mount ............5 Install the Bracket Arms ................6 Connect Spliced Rod (If Applicable) ............6 Install Rings ....................7... -
Page 3: Getting Started
GETTING STARTED Product View—Decorative Drapery Hardware Pleated Style Side Panel or Drapery Finial Bracket Ring Drapery... -
Page 4: Product View-Decorative Drapery Hardware Grommet Side Panels
GETTING STARTED Product View—Decorative Drapery Hardware Grommet Side Panels Finial Grommet Side Panel Bracket... -
Page 5: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Hunter Douglas Design Studio Decorative Drapery Hardware. With ™ proper installation, operation and care, your new drapery/side panels will provide years of beauty and performance. Please thoroughly review this instruction booklet and enclosed packing list before beginning the installation. -
Page 6: Installation
INSTALLATION Install the Brackets — Wall Mount Measure the width of the rod and use this measurement to determine where the ends of ■ the rod will be located. Use a pencil to lightly mark where its ends are located. Use the figure below to mark the locations on the wall for each of the brackets. -
Page 7: Install The Brackets - Ceiling Mount
INSTALLATION Install the Brackets — Ceiling Mount Measure the width of the rod and use this measurement to determine where the ends of ■ the rod will be located. Use a pencil to lightly mark where its ends are located. Use the figure below to mark the locations on the ceiling for each of the brackets. -
Page 8: Install The Bracket Arms
INSTALLATION Install the Bracket Arms Ceiling and Wall Mount with 3" Returns. Install the ■ bracket arms by sliding it completely into the base and tightening the screw to secure it. A ceiling mount bracket Tighten is shown, but the process for wall mount bracket is the Screw same. -
Page 9: Install Rings
INSTALLATION Install Rings Drapery Only Draperies come with bypass rings to allow the drapery to glide over Wand Bypass the bypass brackets. Ring Install the wand bypass ring(s) first. Ensuring the wand(s) are ■ positioned where the leading end(s) will be positioned. Slide the remaining bypass rings onto the rod. -
Page 10: Install Pleated Style Side Panels Or Drapery
INSTALLATION Install Pleated Style Side Panels or Drapery Adjustable Pin in Top Position Ensure all adjustable drapery pins are in the top position. ■ If the pin is not in the top position, slide the pin down and out ➤ of the channel then insert the pin into the channel from the top and you hear a click. -
Page 11: Install Grommet Style Side Panels
INSTALLATION Install Grommet Style Side Panels Securing Place the rod into the brackets. ■ Screw Ensure the rod is level and is seated into the arms evenly. ➤ Gather the side panel and lift one end of the rod and slide the side ■... -
Page 12: Operation
OPERATION Operation (Drapery Only) Pull/push the wand to move the drapery to the ■ desired position. Pull or Push Wand to Move Troubleshooting Problem Drapery height is too high or too low on the drapery rod. Solution Pins are adjustable, refer to “Adjust the Drapery Position” on page 8 to adjust drapery higher or lower. -
Page 13: Care
CARE Remove Drapery (If Necessary) Unscrew the finials from each end of the rod. ■ Unhook the returns from the eyelets on the wall. ■ Start at the center of the rod and gently remove the drapery pins from eyelets on each ■... - Page 14 Notes...
- Page 16 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
