  • Page 1 Operator Manual Version 2 Software...
  • Page 2 Reorder P/N: UC4.5-BC-MANUAL-OPERATOR Rev D (UC4.5 Operator Manual) NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information...

  • Page 3: Table Of Contents

    SAFETY PRECAUTIONS ..................2     KEY FEATURES ...................... 3     SYSTEM DESCRIPTION ..................4     General UC4.5 System Layout ............................4     Height Sensors .................................. 5     Roll Sensors ..................................5     Position Sensors ................................6  ...
  • Page 4 Boom Stability ................................. 43     12.5 Setup Messages ................................44     12.6 Operational Messages ..............................46     STATEMENT OF LIMITED WARRANTY ............47     SPRAYER TYPES ....................48     UC4.5 MENU STRUCTURE ................49    ...

  • Page 5: Introduction

    If you have any questions, feedback or comments regarding the NORAC UC4.5 Spray Height Control system, please contact us. The information in this manual applies to systems with Version 2 software.

  • Page 6: Safety Precautions

    Safety Precautions The UC4.5 Spray Height Control system will greatly improve spray height accuracy and protect the boom against damage in a wide variety of field conditions. However, under some circumstances performance may be limited. The operator of the sprayer must remain alert at all times and override the automatic control when necessary.

  • Page 7: Key Features

    Key Features Non-contact Sensing:  Sensing is done using ultrasonic sensors which means no parts of the UC4.5 Spray Height Control System come in contact with the ground.  Using a non-contact system means there will be no additional forces put on the boom, which could cause damage to the sprayer boom.

  • Page 8: System Description

    System Description General UC4.5 System Layout Figure 1: General UC4.5 System Layout (Self Propelled) Figure 2: General UC4.5 System Layout (Pull Type)

  • Page 9: Height Sensors

     Roll sensors are important for measuring boom and sprayer roll dynamics.  Two roll sensors are normally used for a UC4.5 Spray Height Control System.  The mounting position of the roll sensors vary from sprayer to sprayer depending on boom geometry and suspension.

  • Page 10: Position Sensors

    Control Panel The UC4.5 control panel (Figure 4) is the main component of the UC4.5 Spray Height Control System. The control panel uses the readings from the ultrasonic sensors to control solenoid operated valves that in turn adjust the boom height. The control panel will: ...

  • Page 11: Icon Descriptions

    Icon Descriptions The following table illustrates and describes the icons used on the control panel buttons. Table 1: Button Icons Icon Name Description Sensor Display Navigates to the Sensor Display menu. Navigates to the Settings menu. Settings (No) Declines selections in some menus. Plus Adjusts setting values.

  • Page 12: Operation

     New settings take effect once the run screen is displayed. When the UC4.5 Height Control System is in automatic mode, arrows will appear on the screen indicating the UC4.5 system is making a correction. Often the correction will be very small and there may not be a noticeable change in boom position.

  • Page 13: Sprayer Switches

    Viewing the Sensor or Target Height: When in manual mode the run screen shows the average of all the sensor heights. In automatic mode the number shown on the run screen is the target height. Press to view the actual sensor heights. The left, right, and main (center) sensor heights are each displayed on a separate screen.

  • Page 14: Main Menu Settings

    Main Menu Settings Sensor Mode: Soil mode configures the sensors to read the height from the spray nozzles to the ground. Crop mode will read the height from the spray nozzles to the top of the crop canopy. Hybrid mode will use both the distance measured to the crop canopy and the distance measured to the ground to determine the crop height.

  • Page 15: Main Menu Map

    Display Run Screen M 82 M Setup Sensi 5 Sensitivity Crop or Soil Mode Soil On ReTune ? Retune Hydraulics Control Settings More Figure 6: UC4.5 Main Menu Map Note: Refer to Section 15 for a full menu structure map.

  • Page 16: Understanding The Uc4.5 System

    Understanding the UC4.5 System The UC4.5 Spray Height Control System will work well in most situations. As with any equipment, it is important that the operator remain alert at all times. There may be some situations and terrain where performance is limited and in these situations the operator must resume manual control of the booms.

  • Page 17: Sensing Further Ahead Of The Boom

     Some crops will produce a more varying canopy than others. In these situations, the severe terrain option (Section 9.1) will provide more representative measurements and better performance. Hybrid mode is recommended for uneven crops.  When mounting the main lift height sensor, ensure the sensor does not measure behind a wheel or tramline, when driving straight or turning.

  • Page 18: Setup

    Setup When the control panel is turned on for the first time, the UC4.5 control panel guides the operator through the Automatic System Setup. Normally the UC4.5 Spray Height Control System will automatically configure and calibrate itself to the sprayer. If this process does not produce the desired results, perform the Manual System Setup described in Section 8.3.
  • Page 19  Use the sprayer's manual controls to move the left boom up.  If the wrong boom moves or if the direction is incorrect, stop the setup. Consult the UC4.5 Installation Manual to check the hydraulic plumbing and electrical wiring of the system.
  • Page 20 Press Left Dn Press Rght Up Press Rght Dn Press Main Up Press Main Dn Note: Some sprayer types do not support a wiring test or they may support a different style of test. If there are no messages displayed in this step, simply continue as prompted by the panel. 8.1.5 Sensor Detect Level Booms at...
  • Page 21 8.1.6 Boom Geometry Tuning Exit Cab push boom tip near to ground & let go  Exit the cab and manually push either boom tip down 1 – 3 feet (30 – 90 cm) for a moment and then let go. ...
  • Page 22 8.1.8 System Testing M 39 M  The run screen is shown above. It shows the system is in manual mode with an average height reading of 39 inches (100 cm). CAUTION In the following procedure, switch the control panel to manual mode immediately if the boom movements are erratic.

  • Page 23: Retune

    Retune From time to time it may be necessary to recalibrate (Retune) the UC4.5 electronics to the sprayer’s hydraulics. Examples of such times are:  A hydraulic solenoid valve has been changed.  The hydraulic pump has been changed or adjusted.

  • Page 24: Manual Setup

    Manual Setup The UC4.5 Spray Height Control System will not operate in automatic mode until the system has been configured. It is recommended that the Automatic System Setup be used, but if necessary, a manual system setup may be used. The manual system setup involves setting up each sensor (programming serial numbers and sensor locations) as well as tuning the hydraulic parameters manually.
  • Page 25 Navigating to the Sensor Menu:  Ensure the UC4.5 control panel is in manual mode, at the run screen.  Navigate to the "More?" menu prompt in the SENSOR DISPLAY ( ) menu. Press confirm.  Navigate to the boom section to be changed. Press .
  • Page 26 Calibrating the Sensor’s Height Reading (Zero Height):  Ensure the sprayer boom is unfolded and the sensors are located over bare soil or gravel. Position the boom at a normal working height. Do not conduct this procedure over standing crop or tall grass/weedy areas. It is recommended to perform this calibration in soil mode.
  • Page 27 8.3.2 Valve Tuning Each valve must be tuned correctly for optimum performance from the UC4.5 Spray Height Control System. When setting up the valves, the sprayer booms must have room to move in their full range of motion. Make sure there are no obstructions, such as power lines, that the booms may come into contact with.
  • Page 28 Automatic Dead Zone Calibration:  Follow Section 8.1.1 (level booms, working RPM, etc.) before proceeding.  Ensure the UC4.5 control panel is in manual mode, at the run screen.  Navigate to the "More?" menu prompt in the SETUP ( ) menu.
  • Page 29  Follow Section 8.1.1 (level booms, working RPM, etc.) before proceeding.  Ensure the UC4.5 control panel is in manual mode, at the run screen.  Navigate to the "More?" menu prompt in the SETUP ( ) menu.
  • Page 30  The change in height reading is live as long as the button is held. Wait until the height reading has settled to a stable value and record this reading. This is the boom speed in inches per second (in/s) or mm per second (mm/s). ...
  • Page 31 8.3.3 Boom Geometry Tuning (Push Test) If it desired to redo the push test or if the system has been manually set up and the boom geometry needs to be calibrated, the push test can manually launched. To Manually Launch the Boom Geometry Test: ...
  • Page 32 8.3.4 Turning Booms Off or On The UC4.5 automatic height control can be turned off for each individual boom section. In automatic mode, boom sections that are turned off will not automatically adjust and are indicated with a "D" in the run screen, as shown in Figure 12.

  • Page 33: Quick Install

     When the word "Sensor" is displayed, release the button. The system will be configured with the standard settings based on the type selected and the number of sensors present.  The UC4.5 system will now prompt the operator to perform a push test (Section 8.1.6 - Boom Geometry Tuning).
  • Page 34 ACTIVE ROLL SYSTEM:  Perform the Quick Install for the standard system as previously described. Roll OnA  Navigate to the "Roll ?" menu prompt in the SETUP ( ) menu. Press and then change it to "Roll OnA" using the buttons.

  • Page 35: Optional Kits

    Optional Kits The kits shown below are optional add on kits for the UC4.5 Spray Height Control System. These kits will help improve the performance for certain situations described below. Main Lift Kit  An additional sensor may be added to the centre section of the boom to improve system performance.

  • Page 36: Roll Bias (Active Roll) Kit

    Roll Bias (Active Roll) Kit  Available on certain sprayer models (most sprayers with boom roll capability).  Full boom roll is controlled actively together with wing tilt functions.  Provides active isolation between the boom and sprayer, and increases reaction speed. ...

  • Page 37: Options

    (Section 6.3). Navigating the Headland Assist & Remote Switch Menu:  Ensure the UC4.5 control panel is in manual mode and at the run screen.  Navigate to the "More?" menu prompt in the SETUP ( ) menu.
  • Page 38 Table 3: Headland Assist & Remote Switch Settings Setting Remote Switches Headland Assist Trigger Mode Rems Off Disabled Disabled Disabled Disabled Rems On Enabled Disabled Disabled Disabled Disabled Enabled Main Up / Down Main Lift Enabled Enabled Main Up / Down Main Lift Enabled Enabled...

  • Page 39: Remote Switches

    To activate automatic mode, apply +12 VDC to the remote auto line. The voltage must always be applied after the display has been powered up. The UC4.5 will not go into automatic mode if voltage is applied to the remote auto input line before the system is powered up.

  • Page 40: Changing The Units

     To access the minimum height mode settings; press from the run screen until "More?" is displayed. Press to accept.  Press again until "Other?" is displayed. Press to accept.  Use the buttons to change the settings. Minimum Height Soil Mode (default is 0) Sensor Display Minimum Height Crop Mode (default is 0)

  • Page 41: Maintenance

    11 Maintenance The NORAC Spray Height Control system requires very little maintenance, but there are a few procedures that will ensure the system continues to work correctly for many years. Before each day:  It is highly recommended that the sprayer friction pads are greased. To ensure optimum performance this should be done daily.

  • Page 42: Troubleshooting

    12 Troubleshooting 12.1 General Operation Boom does not appear to be level after system setup:  The sensitivity setting may be too low. Check the sensor height readings, if it differs from the target height then try turning up the sensitivity. The default tolerance for a sensitivity setting of 5 is ±...

  • Page 43: Sensors

    12.2 Sensors Height or roll sensor appears not to work (displays "NC" or "No Comm"):  "NC" or "No Comm" refers to no communication. This may be caused by a damaged or defective CANbus cable. Ensure all cables are connected correctly. The connections should be tight and free of corrosion.
  • Page 44  If the error appears in the new location, the sensor may not be functioning properly. Sensor Alignment: Proper sensor alignment is critical for proper UC4.5 performance.  When the boom is in its lowest position, the sensor mouth must be 22cm (9 inches) or more above the spray nozzles.

  • Page 45: Hydraulics

    Boom(s) will not raise or lower:  Ensure there is hydraulic oil being supplied at the Norac valve block and that there is pressure at the pressure port. The hydraulics will not work if the pressure and tank lines are reversed.
  • Page 46 The hydraulic oil is overheating:  Using the UC4.5 system at higher sensitivities may create a greater demand on the sprayer’s hydraulics. Try lowering the sensitivity.  Plumbing single acting systems as double acting with orifices in both "A" ports may reduce...

  • Page 47: Boom Stability

    12.4 Boom Stability The boom is unstable in automatic mode:  Ensure the sprayer’s boom suspension is operating correctly and moving freely. If the suspension is sticking or too loose the boom will be unstable. If the boom is unstable in manual mode, the height control system will not make it more stable.

  • Page 48: Setup Messages

     This message will be shown if the boom moves in the wrong direction of what is expected by the UC4.5 system. This may be caused by a wiring or hydraulic problem. An extremely under damped boom or high wind conditions may also cause this message to appear.
  • Page 49 The display is stuck at "Mot’n Dly" or "KP Stp 9" during an install or retune:  The sensor may be reading off the boom. Try moving the sensor to a better location.  The target may be too weak. Move the sprayer to a better location with either dirt or gravel on the ground.

  • Page 50: Operational Messages

    12.6 Operational Messages The following messages may appear during normal operation and may not indicate an error with the system. "NR" or "NoRdg":  This indicates the sensor is not receiving a good reading. It is normal to see this message occasionally, however if the message is constantly displayed there may be a problem with a sensor.

  • Page 51: Statement Of Limited Warranty

    Shipping damage is not covered under this warranty. NORAC or its authorized Service Center will repair or replace, at its option, any defective part or component at no cost to the purchaser during the Warranty period. If service in the field is required NORAC will authorize on-site repairs at no charge for parts and labor.

  • Page 52: Sprayer Types

    14 Sprayer Types Table 4: UC4.5 Control Panel Firmware version 2.0.0.0 Sprayer Types Type Sprayer Model Type Sprayer Model Generic Sprayer Boom - North America Hagie 264, 284XP, DTS8, 2100, 2101, DTS10 Generic Active Slant (Use with GN5 kit) Hagie STS...

  • Page 53: Uc4.5 Menu Structure
