- Page 1 F8F-RareBear Pro Assembly Instructions...
- Page 2 1.Assemble the base. 2.Fold hinge for many times to make the rudder surface move freely (also can be cut off and connected with transparent tape).
- Page 3 3. Cut off this part. When the fuselage is combined, the screwdriver can be extended into the adjusting steering arm.
- Page 4 4. Bond the fuselage, pay attention to the difference between the left and right sides of the fuselage.
- Page 5 6. Install aileron servo. The steering gear wire extends from the right side of the fuselage. 7.Insert wing support, pay attention to both sides symmetrical.
- Page 6 8. Insert horizontal tail, pay attention to the symmetry of left and right sides, glue bonding 9. Glue the motor to the nose. The coating sticker can be pasted on the fuselage at this time.
- Page 7 10. Reference to coated stickers.
- Page 8 11. Fold the aileron back and forth many times to make the rudder surface move freely. (It can also be cut off directly and connected with transparent tape.) Sticking transparent tape on both sides to enhance the torsional rigidity of aileron...
- Page 9 Bend the wing along the notch. Installation of the wing.
- Page 10 Installation of the control horns. Connect the pushrod clips with heat shrinkable tube and fix them with glue.
- Page 11 Installation of the pushrods. Installation of the control horns.
- Page 12 Installation of the servos.
- Page 13 Connect the pushrod clips & pushrods with heat shrinkable tube and fix them with glue. Installation of the pushrods.
- Page 14 Attach the receiver to the fuselage with Velcro.
- Page 15 ·The amount of elevator, rudder and aileron is 5 mm for each side. Please adjust the rudder surface to the level before flight test. Explore the ultimate possibility of airplane kits MinimumRC.COM...
