Summary of Contents for Griven CIRCUS 575

  • Page 1 Foglio di Istruzioni Instructions CIRCUS GR 0143 HMI 575 GR 0145 HMI 1200...
  • Page 2: Contenuto Dell'imballaggio

    CONTENUTO DELL’IMBALLAGGIO Controllate attentamente il contenuto del cartone e, in caso di danni al prodotto, contattate il Vs. trasportatore. Nell’imballaggio del presente proiettore sono contenuti i seguenti prodotti: n° 1 Foglio di Istruzioni n° 1 proiettore CIRCUS n° 2 spine jack stereo SICUREZZA Anche se questo apparecchio è...
  • Page 3: Uso Del Proiettore

    della forcella di sospensione: uno per fig.3 installare il proiettore in posizione orizzon- tale (forcella in posizione “A”) e l’altro per la posizione verticale (forcella in posizione “B”). (fig.3) Posizione A Fissaggio del proiettore Posizione B Per il fissaggio del proiettore al supporto, al soffitto o al muro utiliz- zate la staffa di fissaggio provvista di 3 fori Ø...
  • Page 4 Messa a fuoco fig.6 Per la regolazione della messa a fuoco si dovranno utilizzare i pomoli (P-fig.6) situati sotto i relativi obiettivi (B-fig.6). Velocità di rotazione delle piramidi specchiate E’ possibile regolare la velocità di rotazione delle piramidi specchiate, tramite l’uso del relativo potenziometro (V-fig.6) posto sulla parte anteriore del proiettore.
  • Page 5: Manutenzione

    Fusibile per elettronica 5x20 250V 3,25A 5x20 250V 3,25A Temperatura massima di esercizio Temperatura ambiente massima PARTI DI RICAMBIO Tutti i componenti del proiettore CIRCUS 575 e 1200 sono disponibili come parti di ricambio ed il relativo catalogo è disponibile su richiesta.
  • Page 6: Installation

    PACKING Check carefully the content of the box and in case of damage contact immediately your forwarder. The following items are included in the box: n° 1 instructions leaflet n° 1 CIRCUS n° 2 stereo jack plugs SAFETY Even if this lantern is fitted with a safety micro-switch which automatically disconnects power as soon as the lamp cover is opened, we strongly suggest to disconnect the lanterns from mains sup- ply before replacing the lamp.
  • Page 7: Use Of The Lantern

    fig.3 Position A Position B Fixing 3 Ø 14.5mm holes are provided in the fork to attach the lantern to a clamp or bracket. fig.4 Electrical connection 1) Fix the supply cable (2-fig.5) to the terminal block located on the rear part of the lantern (1- fig.5) 2) Connect the lantern to a mains supply of 230V - 50/60Hz.
  • Page 8 Focusing fig.6 To adjust the focusing use the knobs (p-fig.6) loca- ted under the relevant objective lenses. Rotation speed adjustment To adjust the rotation speed of the mirrored cones set the potentiometer located on the front part of the lantern (V-fig. 6) Automatic function If the lantern is not connected to a remote controller, the gobos-change runs automatically in ran- dom sequence.
  • Page 9: Maintenance

    6x30 250V 10A 6x30 250V 20A Fuse 5x20 250V 3,25A 5x20 250V 3,25A Max Working Temperature Max Ambient Temperature SPARE PARTS All components are available for the CIRCUS 575 and 1200 and the exploded diagram and catalo- gue are available on request.
  • Page 12 WORLD LIGHTING CHALLENGE Professional Lighting Manufacturer Via Bulgaria, 16 - 46042 CASTEL GOFFREDO (MN) Telefono 0376/779483 - Fax 0376/779682 - 0376/779552 http://www.griven.com/ e-mail griven@griven.com http://www.griven.it/ e-mail griven@griven.it...
