CLAWBOT BUILDING INSTRUCTIONS
4
Attaching the Potentiometer
Remove the arm motor along with the clutch post and shaft coupler
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
Next, remove the left, bent bar and its screws and nuts
Robotics Systems
®
To attach the Potentiometer,
C-Channel holding the arm
R BOT T
RO O
B
O
C C C
Clawbot 1.0
•
6
