Vex Robotics CLAWBOT Building Instructions page 2

CLAWBOT BUILDING INSTRUCTIONS
Collect the parts and tools from the list below to attach the sensors:
1
Materials
Shaft, 4" Long
Shaft, 5" Long
Screw, 8-32 x 3/8" Long
Screw, 8-32 x 1/2" Long
Screw, 8-32 x 3/4" Long
Nut, 8-32 Keps
Shaft Spacer, Thin (4.6mm)
Shaft Spacer, Thick (8mm)
Standoff, 1" Long
Angle Gusset
Optical Shaft Encoder
Potentiometer
Bump Sensor
Limit Switch
Ambient Light Sensor
Yaw Rate Gyroscope
Line Tracker
LCD Display
Integrated Motor Encoder Kit
Allen Wrench 3/32"
Allen Wrench 5/64"
Open End Wrench 1/4"
#1 Phillips Screwdriver
Pliers
Hacksaw
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
Quantity
1
2
9
2
12
19
8
5
1
2
2
1
1
1
1
1
3
1
1
1
1
1
1
1
1
Robotics Systems
®
Note that this robot can only
be built if you have a standard
Clawbot already assembled
R BOT T RO O B O C C C
Clawbot 1.0 • 2
