RO O
R BOT T
B
O
C C C
CLAWBOT BUILDING INSTRUCTIONS
4
Attaching the Potentiometer
(continued)
Screw the screws and nuts shown below back into place
Finish by putting on the shaft collar we removed earlier
Building Tip - Using Shaft Collars
g
Clawbot 1.0
•
14
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
®
