CLAWBOT BUILDING INSTRUCTIONS
Attaching the Left Encoder
9
x1 x2
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
3/8"
x1
x2
Connect them together
Robotics Systems
®
Take an angle gusset and an encoder
Option A:
This section covers
how to assemble the
external Quadrature
Encoders. If you
would like to use
the Integrated
Motor Encoders, skip
pages 24-31
R BOT T RO O B O C C C
Clawbot 1.0 • 24
