CLAWBOT BUILDING INSTRUCTIONS
9
Attaching the Left Encoder
(continued)
x4
Slide the shaft through the encoder and then place the screws as shown below
Clawbot 1.0
•
30
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
®
