CLAWBOT BUILDING INSTRUCTIONS
5
Attaching the Sonar Sensor
3/4"
x1
x2
x2
x2
Much like the bumper sensor, start with 2 screws and a spacer
Orthographic view
Top-down view
Clawbot 1.0
•
16
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
®
