CLAWBOT BUILDING INSTRUCTIONS
10
Attaching the Integrated Motor Encoders
Option B:
This section covers using the Integrated Motor Encoders. If you built the
external Quadrature Encoders, then skip pages 32-34.
Detailed instructions can be found at:
http://content.vexrobotics.com/docs/inventors-guide/276-1321-INST-0112.pdf
First, take out the two motors on the bottom of the robot's drive train
© 2013 Carnegie Mellon Robotics Academy / For use with VEX
This set of instructions to build the 393
Motors with the Integrated Motor Encoder
was designed by VEX Robotics
Robotics Systems
®
R BOT T RO O B O C C C
Clawbot 1.0 • 32
