DEMO MANUAL DC1928A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 2 CIN3, CIN6
5 2 COUT1, COUT2
7 2 COUT4, COUT8
9 1 C32
10 1 C33
11 1 C19
12 1 C30
13 2 C24, C25
14 1 C26
15 1 C27
16 1 C28
17 1 D1
18 1 D2
23 1 L1
24 2 Q1, Q3
28 1 RSNSE
29 2 R9, R10
31 4 R32, R36, R56, R58
32 1 R33
33 1 R37
34 1 R39
35 4 R38, R53, R57, R59
36 1 R40
37 1 R51
38 3 R49, R50, PTC
39 1 U1
Additional Demo Board Circuit Components
1 2 COUT5, COUT7 (OPT)
2 3 CIN4, CIN5, CIN7,
3 1 COUT3 (OPT)
4 3 C18, C23, C29 (OPT)
5 2 Q2, Q4 (OPT)
6 1 Q5 (OPT)
7 13 R1, R27, R29, R35, R42, R43,
R46-R48, R52, R54, R55, RNTC (OPT)
Hardware-For Demo Board Only
1 8 E1, E2, E4-E11
2 1 JP2
3 1 JP3
4 4 J1-J4
5 2 XJP2, XJP3
6 4
7 1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP, ALUM, 56µF 20% 50V
CAP, X5R 10µF 20% 50V 1210
CAP, POSCAP 150µF 20% 16V 7343
CAP, X5R 22µF 20% 16V 1210
CAP., X7R 10pF 10% 25V 0603
CAP, X5R 1µF 10% 50V 0603
CAP, X5R 0.033µF 10% 50V 0603
CAP, X7R 1nF 10% 25V 0603
CAP, X5R 0.1µF 10% 10V 0603
CAP, C0G 470pF 5% 50V 0603
CAP, X5R 4.7µF 10% 10V 0603
CAP, C0G 100pF 5% 50V 0603
DIODE, 6.8V SOD-323
DIODE, SOD-323
IND., 7µH
XSTR, MOSFET LFPAK
RES, 3mΩ 1% 1W 2512
RES, 100Ω 1% 1/10W 0603
RES, 0Ω 1/10W 0603
RES, 100k 1% 1/10W 0603
RES, 2.2Ω 5% 1/10W 0603
RES, 191KΩ 1% 0603
RES, 10k 1% 0603
RES, 44.2k 1% 0603
RES, 30.1k 1% 0603
RES, 10Ω 1% 0603
IC., LTC3867EUF, QFN 4mm x 4mm
CAP, X5R 22µF 20% 25V 1210
CAP, POSCAP 7343
CAP, 0603
XSTR, MOSFET LFPAK
XSTR, MOSFET, DUAL N-CHANNEL
RES, 0603
TURRET, 0.094"
HEADER, 3-PIN
HEADER, 4-PIN
JACK, BANANA
SHUNT
STANDOFF, SNAP ON
FAB, PRINTED CIRCUIT BOARD
MANUFACTURER/PART NUMBER
SUN ELECT 50HVH56M
TAIYO YUDEN UMK325BJ106MM-T
SANYO, 16TQC150MYF
AVX 1210YD226MAT2A
AVX 06033C100KAT2A
TDK C1608X5R1E105K
AVX 06035D333KAT2A
AVX 06033C102KAT
AVX 0603ZD104KAT
MURATA GCM1885C1H471JA16D
AVX 0603ZD475KAT2A
TDK C1608COG1H101JK
CENTRAL CMDZ6L8
CENTRAL SEMI CMDSH05-4-LTC
WURTH., 7443630700
INFINEON BSC035N04LSG
PANASONIC ERJM1WTF3M0U
NIC NRC06F1000TRF
VISHAY CRCW06030000Z0EA
NIC NRC06F1003TRF
NIC NRC06F2R20TRF
VISHAY CRCW060375K0FKEA
NIC NRC06F1002TRF
VISHAY CRCW060344K2FKEA
NIC NRC06f3012TRF
NIC NRC06f10R0TRF
LINEAR TECH. LTC3867EUH#PBF
MILL-MAX 2501-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
SAMTEC TMM-104-02-L-S
KEYSTONE 575-4
SAMTEC 2SN-BK-G
KEYSTONE 8832
DEMO CIRCUIT 1928A
dc1928af
