Middle Atlantic Products Forward FWD-LB-2A-4PK Instruction Sheet

Tool-less rackmount accessories

Forward by Middle Atlantic

THANK YOU

Thank you for purchasing a Forward Tool-less Rackmount Accessory by Middle Atlantic Products.

Please read these instructions thoroughly before installing or assembling this product.

PRODUCT FEATURES

• No rack screws! Install your rackmount accessories without any hardware.

• Ergonomic design for easy installation and removal.

• Spring loaded clips secure panel into the Forward rackrail.

Instruction Sheet

Tool-less Rackmount Accessories

NOTE: The 2A Lacer Bar (Model No. FWD-LB-2A-4PK) is pictured.

100-00013

Rev A

Table of Contents

Do you have a question about the Forward FWD-LB-2A-4PK and is the answer not in the manual?

Page 1 Tool-less Rackmount Accessories NOTE: The 2A Lacer Bar (Model No. FWD-LB-2A-4PK) is pictured. THANK YOU Thank you for purchasing a Forward Tool-less Rackmount Accessory by Middle Atlantic Products. Please read these instructions thoroughly before installing or assembling this product. PRODUCT FEATURES •...
Page 2 National Electrical Code or codes administered by local authorities. All electrical products may present a possible shock or fire hazard if improperly installed or used. Middle Atlantic Products, Inc. electrical products may bear the mark of a Nationally Recognized Testing Laboratory (NRTL) and should be installed in confor- mance with current local and/or the National Electrical Code.
Page 3 INSTALLING YOUR ACCESSORY NOTE: This instruction sheet covers the general installation of Tool-less Rackmount Accessories using the 2A Lacer Bar (Model No. FWD-LB-2A-4PK). All of the Tool-less Rackmount Accessories install similar to the method explained in this topic. NOTE: 1. Fasten the hook on one side of your accessory into your desired center Center hole hole as shown.
Page 4 Factory Distribution United States: New Jersey, California, Illinois - Canada: Ontario - The Netherlands: Weert At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company. Page 4...
