The Fans Inside The Netra T1 Server - Sun Microsystems Netra T1 AC200 Product Notes

For information about transferring the system configuration card from one server to
another, refer to the Netra T1 AC200 and DC200 Server User's Guide (part number 806-
5978-10).

The Fans Inside the Netra T1 Server

The Netra T1 contains four fans. These fans are monitored by the LOMlite2 device,
so you can use the Lights-Out Management (LOM) commands to check their status.
Note –
The arrangement of the components inside the Netra T1 AC200 and DC200
servers is not the same as it was inside the Netra t1 Model 100 and 105 servers. The
fans are also numbered and positioned differently. For a diagram showing which fan
is which inside a Netra T1 server, and for information about using the LOM
commands, refer to the Netra T1 AC200 and DC200 Server User's Guide (part number
806-5978-10).
Additional Information on Installing a
Hard Disk Drive
For full instructions on installing a hard disk drive, refer to chapter 4 of the Netra T1
AC200 and DC200 Server User's Guide (part number 806-5978-10). In addition to these
instructions, read the following tip.
Tip –
When inserting a hard disk drive into its enclosure, make sure the top of the
disk drive is touching the top of the enclosure. If you try to install it with the bottom
of the disk drive touching the bottom of the enclosure, the drive will not align with
the slide rails inside the enclosure, and you will not be able to insert the drive.
7
