Section 2: ELECTRICAL INSTALLATION
3. ROUTE 2
a. A second CAN Cable Assembly (30243), also a 25 meter shielded cable, and the largest
connector is a molded plug with maximum outer diameter of .58 inch (14.8mm)).
b. The additional CAN Cable Assembly must be routed in the vessel from the 1
Station (female end) to the 2
4. INSTALL 2
a. The 2
Electrical Equipment Mounting Instructions in Section 2.1.
5. CONNECT 2
a. The 2
Diagram, 90310.
Product:
INSTALLATION
MANUAL
SEAKEEPER 26 GYRO
ND
OPERATOR STATION CABLE
ND
OPERATOR STATION EQUIPMENT
nd
Operator Station equipment is installed at the determined location using
ND
OPERATOR STATION EQUIPMENT
nd
Operator Station equipment is connected in accordance with the Cable Block
nd
(male end) Operator Station.
Document #:
Rev:
90265
2
11 of 12
st
Operator
Page:
