Seakeeper 18 Installation Manual

Hide thumbs Also See for 18:

Advertisement

Quick Links

Download this manual
INSTALLATION MANUAL
*THIS MANUAL ALSO COVERS THE SEAKEEPER 16 MODEL*
NOTE: THIS APPLIES TO SEAKEEPER 16 MODELS AFTER SERIAL No. 16-201-XXXX or LATER
August 2020, Revision 2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 18 and is the answer not in the manual?

Questions and answers

Related Manuals for Seakeeper 18

Summary of Contents for Seakeeper 18

  • Page 1 INSTALLATION MANUAL *THIS MANUAL ALSO COVERS THE SEAKEEPER 16 MODEL* NOTE: THIS APPLIES TO SEAKEEPER 16 MODELS AFTER SERIAL No. 16-201-XXXX or LATER August 2020, Revision 2...
  • Page 2 Product: Document #: Rev: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 SEAKEEPER 16 / 18 INSTALLATION MANUAL AUGUST 2020 Contents: Section 1 – Mechanical Installation & PC-120 Guide Section 2 – Electrical Installation Section 3 – Cooling Installation Section 4 – Startup Section 5 –...
  • Page 3 This document is intended to give details and guidance to a boat builder or equipment installer to install the Seakeeper 16/18. The Seakeeper 16/18 can produce vertical loads up to 26.5KN (5,965 lbs.), longitudinal loads up to 15.61KN (3,409 lbs.), and transvers loads of 2.22KN (500 lbs.) at each of the four mounts.
  • Page 4 While handling / installing the Seakeeper assembly, do not allow electrical fittings that exit bottom of the Seakeeper enclosure to come in contact with any surface or object as this could damage the fittings and potentially affect the vacuum integrity of the enclosure.
  • Page 5 Overhead access or sufficient clearance for removal / re-installation of the Seakeeper for overhaul in future years. • The Seakeeper should be installed in a dry space to minimize effects of corrosion. • Clearance for all recommended scheduled maintenance and any repairs is necessary (see...
  • Page 6 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 4 of 22 Section 1: MECHANICAL INSTALLATION...
  • Page 7 90549 5 of 22 Section 1: MECHANICAL INSTALLATION VIEWS SHOWING RECOMMENDED CLEARANCES AROUND THE SEAKEEPER FOR USE OF HAND TOOLS, EASE OF MAINTENANCE, INSTALLATION AND PROPER OPERATION. FIGURE 2 – INSTALLED SEAKEEPER CLEARANCE CONSIDERATIONS FIGURE 3 – TRANSVERSE BEAMS CLEARANCE CONSIDERATIONS...
  • Page 8 Seakeeper noise has been measured under steady state conditions (no wave load) in Seakeeper's lab and in our test boat. The steady state noise is typically in the range of 66-68 dB un-weighted. As the frequencies emitting the highest sound pressures are low (like other marine machinery), it is recommended that the Seakeeper be installed in a machinery space that is already treated with soundproofing.
  • Page 9 7 of 22 Section 1: MECHANICAL INSTALLATION Selection of Installation Method The Seakeeper 16/18 can be affixed to the hull structure using two methods: 1) Bolt-In installation or 2) Bond-In (Saddle) installation. See figures below. OPTION 1- DIRECT FASTENING OF SEAKEEPER FOUNDATION TO SHIPS STRUCTURE...
  • Page 10 The foundation would fasten directly to hull structure using isolation gaskets and 16x M14X2.0 fasteners. Depending on the structural arrangement to which the Seakeeper is fastened, blind threaded holes or thru-bolting can be utilized. OPTION 2- SADDLE INSTALLATION (4 PLACES)
  • Page 11 4) Remove top and angled face cover panels to access lifting eyes. 5) Attach spreader bar (Seakeeper #80061) to the two lifting eyes located on the top of the Seakeeper enclosure. Stay clear of any other parts on the Seakeeper. The Seakeeper weighs 1030 kg (2,270 lbs.).
  • Page 12 Method. Important dimensional and load information is given in this drawing that will impact the design details of the structure that will receive the Seakeeper. It is assumed that a proper structural analysis has been performed for the hull structure to which the Seakeeper will be fastened to ensure proper strength margins for the loads the Seakeeper will create during operation.
  • Page 13 INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 11 of 22 Section 1: MECHANICAL INSTALLATION CAUTION: Tight clearances from cable guide bands to hull structure. See above figure for dimensions and reference Seakeeper drawing NO. 90544 for complete Seakeeper 16/18 envelope.
  • Page 14 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 12 of 22 Section 1: MECHANICAL INSTALLATION 1.5.2 Transfer of Holes to Boat Structure 1) Lower assembled fixture onto hull structure. The four areas where the feet of the Seakeeper will rest should be coplanar to within .06”...
  • Page 15 Check isolation gasket alignment by test fitting bolts without any obstructions. 2) Lower Seakeeper into position onto the hull foundation beams and align over drilled holes. 3) Install Seakeeper supplied M14 fasteners–...
  • Page 16 .13” inches (3 mm) for consistent adhesive bond gap. In addition, the four areas on top of the saddles on which the feet of the Seakeeper foundation will rest need to be co-planar within .06” (1.5 mm) to minimize potential distortion of Seakeeper support frame when installed.
  • Page 17 Seakeeper’s recommended range of 1 to 3mm (.04” to .13”). Note: Do NOT use the installation fixture to establish Seakeeper envelope dimensions. Refer to Drawing No. 90545 for envelope dimensions. A 3-D model of the Seakeeper is available on the Seakeeper website (www.seakeeper.com) to aid in designing the Seakeeper foundation and the space around the Seakeeper.
  • Page 18 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 16 of 22 Section 1: MECHANICAL INSTALLATION FIGURE 7 – SADDLE INSTALLATION FIXTURE ON NOTIONAL HULL STRUCTURE 1.6.2 Fiberglass Hull Preparation...
  • Page 19 2) Mask hull area (Fig 9) around foundation saddles for easy clean-up and to create outline of surface area to receive adhesive as (Fig 8). Ensure that the bond gap is within Seakeeper’s recommended thickness, or 3mm if using Plexus MA590. FIGURE 9 - MASKING PERIMETER OF SADDLES 3) Raise fixture clear of foundation.
  • Page 20 7) Re-position installation fixture on girders and double-check that the adhesive gap is within the adhesive manufacturer’s maximum recommended thickness. Seakeeper recommends a maximum gap of 3mm if using Plexus MA590. Note if bonding saddles to a metal structure, contact Seakeeper for hull preparation instructions.
  • Page 21 5) If using Plexus MA590 adhesive, apply one coat of Plexus PC-120 surface conditioner to inside surfaces of Seakeeper foundation saddles in accordance with manufacturer instructions. These instructions are located at the end of this section. If using an alternate adhesive, check with manufacturer if any surface conditioner/etch is required for the aluminum saddles.
  • Page 22 Section 1: MECHANICAL INSTALLATION 1.6.4 Bonding Saddles to Hull Note: If using Plexus MA590 adhesive, the Seakeeper saddles should be installed when PC- 120 is confirmed dry. 1) Assemble Plexus cartridge into either the manual or pneumatic gun as shown. Remove cap on cartridge and attach mixing tip.
  • Page 23 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 21 of 22 Section 1: MECHANICAL INSTALLATION 5) Apply large bead of Plexus adhesive to the hull structure as shown in the figure to the right. Apply approximately...
  • Page 24 Allow adhesive to cure per manufacturer’s recommendations. Follow adhesive guidelines for curing time versus temperature prior to removing the fixture. 12) Bonding of Seakeeper saddles onto the hull is now complete. Remove installation fixture. 1.6.5 Installation of Seakeeper The four areas where the feet of the Seakeeper will rest should be coplanar to within .06”...
  • Page 25 Reference Documents & Drawings 90243 Seakeeper 16 Hardware Scope of 90467 2 Helm Control Station Kit Supply 90539 Seakeeper 16/18 Cable Block 90538 Seakeeper 18 Hardware Scope of Diagram Supply 90438 Touchscreen Display Envelope 90550 Seakeeper 16/18 Operation Manual and Mounting Details...
  • Page 26 30298, Color Display 30300, USB 30301, CAN, 2ft 30243, CAN, 25M Extension Cable Cable Cable 20455, DC Seawater Pump, Output Power, 20454, DC Seawater Pump, Input Power, Male-Female Cable, 5M Female Only Cable, 5M FIGURE 1 – ELECTRICAL EQUIPMENT FOR SEAKEEPER 16/18...
  • Page 27 1. TOUCH DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT a. Console space required: Approx. 5.24 W x 3.70 H inches (133 x 94 mm) b. Mounting Instructions, Surface Mount: See drawing 90438 for details. Seakeeper Touch Display 3D Model available upon request.
  • Page 28 TB 90479, SIMRAD AND SEAKEEPER COMPATIBILITY iv. Additional MFD Compatibility will be added as new integrations become available. Please contact Seakeeper for additional information. b. Seakeeper MFD Compatibility cable part numbers can be found in the relevant technical bulletin for the specific MFD, listed above.
  • Page 29 1. 230 VAC POWER SOURCE REQUIREMENTS a. 230 VAC (nominal), 1 Phase, 50/60 Hz, 25 Amps. b. A separate circuit breaker should be used for each Seakeeper’s Drive Box. 2. DRIVE BOX AC POWER INPUT CONNECTION INSTRUCTIONS CSA), 10’ (3m) length, Seakeeper supplied pre- a.
  • Page 30 Cable 8: 20454, DC Input Power, 14 AWG, DTP Female Only, Cable Assembly, Seakeeper supplied (5 meter length) c. Seakeeper 30322, Seawater Pump rated at 24 VDC, Fuse or Circuit Breaker 10 Amps Required i. Alternative: Seawater Pump rated at 24 VDC, Max Fuse Rating Labeled by MFR...
  • Page 31 Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 7 of 13 Section 2: ELECTRICAL INSTALLATION iii. Locate CABLE 8: 20454, DC Seawater Pump Input Power Cable, Female Only connection to the DC “Seawater Pump-In” from the Wire Harness.
  • Page 32 24 VDC, 10 Amps. 2 x 12AWG (3 x 4mm CSA) customer supplied. i. Install Seakeeper provided DC Power Input Cable, P/N: 20248 as CABLE 1. 1. Route CABLE 1 to DC Power Distribution Panel. 2. Terminate RED conductor to +24 VDC. Terminate BLACK conductor to 24V Rtn or Zero VDC.
  • Page 33 Install CABLE 6 (10AWG or 22.0 mm , Customer supplied) from the M6 brass ground stud on the Seakeeper rear brace to a suitable vessel ground. Note: ONLY USE THIS LOCATION FOR GROUNDING THE SEAKEEPER TO THE VESSEL GROUND.
  • Page 34 The operator display should be located on the bridge console. c. Figure 9 below shows the CANbus communications link for the Operator Station. The Terminator goes on one the far end of the Tee Adapter from the Seakeeper. FIGURE 9 – SERIAL COMMUNICATIONS LINK FOR OPERATOR STATION 2.
  • Page 35 Operator Station Kit. Reference Drawings 90467 Helm Display 2 Operator Station Kit 90539 Seakeeper 16/18 Cable Block Diagram (includes detail of 2nd Operator Station) 1. DETERMINE LOCATION OF 2 OPERATOR STATION a. The desired location of the 2 Operator Station must be determined with respect to the 1 Operator Station and the vessel arrangement.
  • Page 36 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 12 of 13 Section 2: ELECTRICAL INSTALLATION 3. ROUTE 2 OPERATOR STATION CABLE a. A second CAN Cable Assembly (30243), also a 25 meter shielded cable, and the largest connector is a molded plug with maximum outer diameter of .58 inch...
  • Page 37 Product: Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 13 of 13 Section 2: ELECTRICAL INSTALLATION Display Installation Template The following template is for mounting; before using this template, measure to ensure that the shown size is actual.
  • Page 38 SEAKEEPER 16 / 18 90549 1 of 5 Section 3: COOLING INSTALLATION Introduction The Seakeeper 16/18 is shipped with the cooling circuit filled and ready for use, only a confirmation of glycol level is required. FIGURE 1 – SEAKEEPER 16/18 COOLING COMPONENTS...
  • Page 39 INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 2 of 5 Section 3: COOLING INSTALLATION FIGURE 2 – SEAKEEPER 16/18 COOLING COMPONENTS Reference Drawings • 90243 Seakeeper 16 Hardware Scope of Supply • 90538 Seakeeper 18 Hardware Scope of Supply •...
  • Page 40 Installer is responsible for supplying a dedicated seawater pump and associated plumbing. Sea water connections on the Seakeeper heat exchanger mate with ¾ inch (19 mm) hose. Seakeeper DC Seawater Pump, 24 VDC (P/N 30322) is available as an option from Seakeeper.
  • Page 41 Document #: Rev: Page: INSTALLATION MANUAL SEAKEEPER 16 / 18 90549 4 of 5 Section 3: COOLING INSTALLATION Mix 50% ethylene glycol with 50% distilled water in a clean container. Refer to Table 1 or glycol manufacturer’s literature for freezing points.
  • Page 42 Section 3: COOLING INSTALLATION • Seawater cooling is not required when the Seakeeper is powered off and the flywheel is coasting to a stop The cooling system is self-purging. If small amounts of air are in the system, they will most likely be dislodged during the first sea trial.
  • Page 43 Section 4: STARTUP Introduction This section describes the first startup of the Seakeeper. Also reference Seakeeper Document # 90550, Seakeeper 16 / 18 Operation Manual. • Previous sections for mechanical, electrical and cooling installation must be completed before this startup sequence is initiated.
  • Page 44 11) During normal operation, the Seakeeper should be stopped when stabilization is no longer required. This maximizes long term life as it allows the Seakeeper to start the coast down cycle before cooling is shutoff. Once the vessel is secured in the slip and the crew has shut down the generator and engines, the AC and DC breakers that control the Seakeeper should be switched to the OFF position.
  • Page 45 Mechanical Checklist (reference Installation Manual Section 1) ❑ Seakeeper Foundation Installed in Hull ❑ Foundation bolts torqued to specification Electrical Checklist (reference Seakeeper Drawing 90539 & Installation Manual Sec. 2) Mount Components ❑ Display (near helm) Connect Customer Supplied Cables ❑...
  • Page 46 Follow instruction in Section 4.1 of Installation Manual to turn off the Seakeeper ❑ The Seakeeper is powered off by switching off the AC & DC power and seawater pump. The Seakeeper will automatically be in LOCK mode once the system is turned off ❑...
  • Page 47 Circuit Breaker, AC, 2-Pole, 20 Amp 2.2.2 Dwg 90539 Electrical Circuit Breaker, DC, 1-Pole, 10 Amp 2.2.2 Dwg 90539 Electrical M6 terminal lug for grounding Seakeeper at rear 2.3.1 Electrical brace Cable, 10 AWG, for grounding Seakeeper at rear 2.3.1 Dwg 90539 Electrical...
