EC531-SD/EC532-SD Installation Guide
• 1 EC531-SD/EC532-SD system unit
• Mounting screws for SATA drive
• Mounting screws for Mini PCIe module
DIO COM4 COM5 COM6
Line-out
Microphone
Notes:
1. Please gently press the power button to avoid possible damages.
2. The HDMI is a DP/HDMI combo port but can only transmit HDMI signals (unless wired as a DP port by
request). Please plug in an HDMI cable with the right orientation and alignment to avoid damage to the
connector. You should feel resistance (due to a pin on the right) if the cable is not inserted correctly.
For detailed instructions, please see a video at https://youtu.be/SUj07rfN5l8.
Aligning side
(left)
DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and details of the
installation process, please refer to the user's manual.
Package Contents
Panel
HDMI
DVI-I
(DVI-D signal)
DC-in
Expansion slots
Angled-corner
pin
www.dfi.com
1
(2)
USB 3.0
LAN 1 LAN 2
SATA 2 SATA 1
Remote
Power on/off
Angled-corner
(up)
Status LED (Orange)
HDD LED (Red)
(1)
Power Button
with LED (Green)
USB 3.0
VGA
COM 1
COM 2
COM 3
Align this edge with the
left side of the connector
