The material is fed by an index with hydraulic vises, which clamp the piece and move it under the blade. The index moves
on round chrome guides located underneath the roller table, and it is controlled by an hydraulic cylinder. The index has two
speeds: fast to quickly approach to the set lenght and slow to precisely position the piece. Anencoder (with a precision of a
tenth of a millimeter) controls the positioning of the index.
2.5. V
ISES
Vises are hydraulic. The jaws are tempered.
TAB 2.3
Description
On the length
On the perpendicularity
3. HOW TO USE THE INSTRUCTION MANUAL
3.1. W
HO SHOULD READ THE INSTRUCTION MANUAL
Description
Instruction Manual
Electrical Schematic
The electrical schematic is included in this manual and cannot be supplied separately.
3.2. W
HERE TO KEEP THIS MANUAL
This manual, that is provided along the machine in one copy, should be kept where the machine is located, in a safe and pro-
tected place, to be consulted if necessary.
3.3. S
TRENGTH OF THIS MANUAL
1. This manual reflects the state of the art at the time the machine was built, and cannot be considered replaceable by a
newer version.
2. This manual has full force for all the life of the machine it goes along.
3. The customer is not allowed to copy totally or partially this manual to reach goals different than the one of the origi-
nal manual, and to avoid that a partial documentation replaces the original one.
3.4. M
ANUAL UPDATE
Cutting tolerances
mm
mm
TAB 3.1 Who should read the manual
Machine
C-260 NC
±0,15 mm / 500 mm
±0,2 mm /100 mm
?
Operator
Mechanical
Yes
No
Pag.9
Edition A
Internal service
Electrical
Yes No
No Yes
