Sophia 5 Drawer Chest
Assembly Instructions -
Dimensions
Width - 80cm
Depth - 41.5cm
Height - 115.6cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800.
For further assistance please visit http://www.argos-support.co.uk/.
Please keep for future reference
496/6834
459/4127
483/9019
Issue 1 - 05/05/16
Advertisement
Related Manuals for Argos Sophia 5 Drawer Chest
Summary of Contents for Argos Sophia 5 Drawer Chest
- Page 1 Depth - 41.5cm Height - 115.6cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/. Issue 1 - 05/05/16...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly · Do not stand or put weight on · Check you have all the · To reduce components and tools listed on the product, this could cause the likelihood of pages 2 and 3.
- Page 3 If you have damaged or missing componets, call the Components - Panels Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/ Please check you have all the panels listed below Left Side × 1 Right Side × 1 Top × 1 (92 ×...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel Large locking Large locking ×...
- Page 5 Assembly Instructions Step 1 a:Insert Wooden dowels into Left side Right side b: Fix Runner Outside Left onto Left side by using Screws c: Fix Runner Outside Right onto Right side by using Screws d: Insert Large locking into Left side and Right side Note: Insert locking pin as shown.
- Page 6 Assembly Instructions Step 3 Fitting locking pins Insert Large locking Pin into Top ×6 Note: Insert locking pin as shown. Do not over tighten. Step 4 Fixing legs to Base frame Fixing Legs to Base Fram by using Screw Washer &...
- Page 7 Assembly Instructions Fitting locking pins Fitting Locking pins Base Fram Note: Insert locking pin as shown. Do not over tighten. Step 6 ×6...
- Page 8 Assembly Instructions Step 7 Attach the Sides unit to Base frame Insert Large locking nut to the sides as show on picture. Use screw driver turn locking nut clockwise to lock. ×6 Step 8 Insert back panel Connect 2 Back panels by H shape plastic bar then Slip the Back panels to the groves on the Sides.
- Page 9 Assembly Instructions Step 9 Attaching Top Attach Top to the unit. Insert Locking Nuts to the Sides where shown and use a screw ×6 driver to turn locking nuts clockwise to lock. ×2 Step 10 Fix Back panel: ×2 ×2 Fix Back panel onto ×2...
- Page 10 Assembly Instructions Step 11 Drawer assembly a: Insert Small locking into holes shown on back of Drawer front Note: Insert Locking pin as shown. Do not over tighten. b: Attach Drawer sides and Drawer support rail to Drawer front Insert Small locking nuts into Drawer Sides and Drawer support rail .
- Page 11 Assembly is finished. If you need help or have damaged or missing parts,call the Customer Helpline: 03456 400800 Retailer: Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9,2NW For further assistance please visit http://www.argos-support.co.uk/...
-
Page 12: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
