SKYE WOOD / WHITE TV UNIT
Assembly lnstructions - Please keep for future reference
451/8969(D)
Dimensions
Width - 100cm
Depth - 39.5 cm
Height - 53 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Issue 1-16-04-15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos SKYE WOOD
Summary of Contents for Argos SKYE WOOD
- Page 1 SKYE WOOD / WHITE TV UNIT Assembly lnstructions - Please keep for future reference 451/8969(D) Dimensions Width - 100cm Depth - 39.5 cm Height - 53 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800...
- Page 2 Safety and Care Advice Assemble the item as close We do not Check you have all the components and tools listed on to its final position (in the same recommend the pages 2 and 3. use of power room) as possible. drill/drivers for Remove all fittings from the Assemble on a soft level...
-
Page 3: Components - Parts
Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 Right side panel x 1 Shelf x 1 (39.2x37x1.5cm) (47.6x33.5x1.5cm) Left side panel x 1 Divider x 1 (39.2x37x1.5cm) (37x37x1.5cm) Foot x 4 Base panel x 1 Support bar x 1 (12.3x4x4cm) - Page 4 Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 Drawer left panel x 1 Back panel left x 1 (48.3x37.7x0.3cm) (30x11.9x1.2cm) Drawer back panel x 1 Drawer right panel x 1 (42.8x11.9x1.2cm) (30x11.9x1.2cm) Drawer bottom panel x 1 14 Drawer front panel x 1...
- Page 5 Components - Fittings 0345 6400 800 Cam bolt x 14 Dowel x 16 Slide left x 1 3 x 12 Wood screw x 12 Slide right x 1 Cam-lock x 10 Allen key x 1 Washer x 4 Hexagon Screw x 4 4 x 40 Protector x 4 4 x 30...
- Page 6 Assembly Instructions Step 1 Preparing shelf and side panel Insert dowels into end of middle shelf right side panel shown. Step 2 Preparing divider and side board Plug dowels into end of divider and left side panel Screw cam-bolts into divider and left side panel...
- Page 7 Assembly Instructions Step 3 Assembling side panel and divider Fix left side panel shelf and divider together with cam-lock F as shown. Note : Please pay attention to direction of each board. Step 4 Assembling feet Fix feet on base panel with hexagon screws and washer Stick protector...
- Page 8 Assembly Instructions Step 5 Assembling base panel Fix base panel divider and side panel with wood screw as shown Note: Please pay attention of direction of board Step 6 Preparing top panel Screw cam-bolts into top panel as shown...
- Page 9 Assembly Instructions Step 7 Assembling back panel and top panel Slide back panel into groove, fix top panel with cam-lock as shown. Back panel 9 and 10. Step 8 Assembling drawer frame Fix drawer side panel and back panel together with wood screw as shown.
- Page 10 Assembly Instructions Step 9 Preparing drawer front panel Screw cam-bolts into drawer Front panel as shown. Step 10 Assembling drawer Slide drawer bottom into groove , fix drawer front panel with cam-lock as shown...
- Page 11 Assembly Instructions Step 11 Assembling slide Fix slide on drawer with wood screw shown Step 12 Slide drawer into cabinet...
- Page 12 Assembly Instructions Step 13 Assembling adjustable shelf Plug in shelf pins , put adjustable shelf shelf pins Step 14 Preparing door Fix sliding door roller and sliding door pin door panel as shown...
- Page 13 Assembly Instructions Step 15 Assembling door Put roller into plastic groove, move door to make pins aim at top groove, then push button to stick out pins to lock door. Step 16 Assembling door Slide door to make sure it goes smoothly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group.
