Star 2+2 Drw. Chest White
Assembly Instructions
8053011
- Please keep for future reference
Dimensions
Length - 86cm
Depth - 40cm
Height - 73cm
Weight - 26,4kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 06/10/17
Advertisement
Related Manuals for Argos Star 8053011
Summary of Contents for Argos Star 8053011
- Page 1 Star 2+2 Drw. Chest White Assembly Instructions 8053011 - Please keep for future reference Dimensions Length - 86cm Depth - 40cm Height - 73cm Weight - 26,4kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2 and 3.
-
Page 3: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Top x1 Side panel Right x1 Side panel Left x1 (86.0x40.0x1.6cm) (65.4x36.1x1.2cm) (65.4x36.1x1.2cm) No. 4301-1608601-40 No. - Page 4 Components - Parts If you have damaged or missing components, call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Back panel x1 Drawer base x2 (62.8x77.2x0.3cm) (72.8x34.8x0.3cm) No. 4309-030628 No. 4309-0307281...
- Page 5 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 4020-007 No. 3933-15010 No.
- Page 6 Assembly Instructions Step 1 Insert the dowels into the holes in cross rail It may be necessary to tap the dowels in very gently with a small hammer. Attach minifi x bolts top panel Step 2 Attach the side panels to the legs using screws Make sure the top of...
- Page 7 Assembly Instructions Step 4 Attach the second drawer runner to the partition with euro screws Be aware of the front edge! Note that the drawer screws must be inserted from different holes in the runners! Front edge Step 5 Insert the dowels the holes in the side panels Attach minifi...
- Page 8 Assembly Instructions Step 6 Attach the cross rail to the side panels with the minifi x cams Step 7 Attach angles to the plinth using screws Attach plinth to side panels using screws Step 8 Attach the partition the top panel using minifi...
- Page 9 Assembly Instructions Step 9 Attach the top to the side panels with the minifi x cams Step 10 Fasten the list to the top panel using screws , placing the screws into the marking holes in Don’t overtighten.
- Page 10 Assembly Instructions Step 11 Attach the back panel with nails to the back side of the chest. Nail the back panel to the carcass, ensuring that there are NO GAPS between the and the back panel . Follow the measurements. Step 12 Measure out the positions for the wall...
- Page 11 Assembly Instructions Step 12b Different types of wall fi ttings. Contact your local DIY or hardware store for the wall plugs Concrete/Brick wall and screws. Plaster wall Wooden wall Step 13 Insert the dowels into the holes in the drawer sides Attach the minifi...
- Page 12 Assembly Instructions Step 14 Attach the drawer sides to the drawer front with the minifi x cams Repeat for both drawers. Step 15 Push the drawer base carefully into the drawer. Note that one edge of the base is slightly narrower (11 mm) than the other, make sure the narrow edge goes in fi...
- Page 13 Assembly Instructions Step 17 Push the drawer base carefully into the drawer. Attach the drawer back to the drawer sides with the screws Repeat for both drawers. Step 18 Place the assembled drawer between the drawer runners Attach the drawer sides to the runners using the screws Repeat for all drawers.
