Argos Stirling Assembly Instructions Manual

2 drawer 3 door mirrored robe

Hide thumbs

page of 24

/ 24
Bookmarks

Quick Links

Download this manual

Stirling -

Assembly Instructions -

Dimensions

Width - 106.5cm

Depth - 49cm

Height - 189cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

2 Drawer 3 Door Mirrored Robe

Please keep for future reference

339/3130

330/9409

MADE IN

BRITAIN

Issue 1 - 11/11/14

Need help?

Do you have a question about the Stirling and is the answer not in the manual?

Questions and answers
