Darcy - TV Stand
Assembly Instructions - Please keep for future reference
392/5591
Dimensions
Width - 159.3 cm
Depth - 50 cm
Height - 53.7 cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400 800
Issue 1 - 03/06/2015
1
Advertisement
Related Manuals for Argos Darcy TV Stand 392/5591
Summary of Contents for Argos Darcy TV Stand 392/5591
- Page 1 Darcy - TV Stand Assembly Instructions - Please keep for future reference 392/5591 Dimensions Width - 159.3 cm Depth - 50 cm Height - 53.7 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400 800 Issue 1 - 03/06/2015...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assemb ly • Check you have all the • Assemble on a soft level • Dispose of all packaging components and tools listed on surface to avoid damaging the carefully and responsibly.
- Page 3 If you have damaged or missing components Component - Panels call the Customer Helpline: 0845 6400 800 Please check you have all the panels listed below Left side Right side (44.6 x 49.8cm) (44.6 x 49.8cm) (159.3 x 50.0cm) Shelf Vertical Bottom (57.5 x 42.8cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Wooden dowel x 56 Hinge plate x 2 Door hinge x 2 (8x35) Locking nuts x 12 5x13mm Screw x 12 ( 15x13) 4x13mm Screw x 4 Hexagon bolt x 10 Cap x 12 Metal dowel x 12 (7x50)
-
Page 5: Tools Required
Tools required Phillips screwdriver Small (medium & large) hammer Ruler/tape Flatblade screwdriver Drill measure (medium) Eye protection (when using a Punch hammer or glue) Assembly instructions Step 1 Step 1 a: Inserting dowels and locking nuts Insert locking nuts into the right side panel Insert wooden dowels into the right side panel Screw metal dowels... - Page 6 Assembly Instructions Step 1 Step 2 a: Inserting dowels and locking nuts Finished front edge Insert locking nuts into the vertical partition Insert wooden dowels into the vertical partition Screw metal dowels Rotate vertical partition. Insert shelf support into the vertical partition. WARNING! Please wear goggles or...
- Page 7 Assembly Instructions Step 1 Step 2 Step 1 Step 3 a: Inserting dowels and locking nuts Insert locking nuts into the left side panel Insert wooden dowels into the left side panel Insert shelf support into the left side panel. WARNING! Please wear goggles or...
- Page 8 Assembly Instructions Step 4 a: Inserting dowels Screw metal dowels into the top Insert shelf support Attach “hinge plates" into the bottom Step 5 Insert locking nuts into the front support Repeat with back support Insert wooden dowels into the front support Repeat with back support WARNING!
- Page 9 Assembly Instructions Step 6 Fitting hinges to doors Fix 2 hinges to the flap using screws Step 7 Insert wooden dowels into the long plinth Repeat with short plinth...
- Page 10 Assembly Instructions Step 8 Attaching panels Attach right side panel to the front support Attach vertical partition to the front support Use the allen key turn locking nuts clockwise to lock Cover locking nuts with caps Step 9 Attaching panels Attach right side panel Attach vertical partition Attach left side panel...
- Page 11 Assembly Instructions Step 10 Attaching rear panel Slide rear panel into grooves of , side panels Step 11 a: Attaching plinth Attach feet to the long plinth Attach long plinth to the short plinth b: Attaching plinth Attach long plinth &...
- Page 12 Assembly Instructions Step 12 Mounting bracket Place mounting bracket onto the assembly as shown. Mark holes with a punch and fix the bracket with screws WARNING! Please wear goggles or protective eyewear whilst hammering sliders in place. Step 13 Attaching bottom Attach bottom to the sides &...
- Page 13 Assembly Instructions Step 14 Fixing rear panels Fix rear panel to back of TV stand using stabilizer IMPORTANT ! Cabinet MUST be “square” when rear panel is attached.
- Page 14 Assembly Instructions Step 15 Drawer assembly a: drawer back: Insert wooden dowels into the drawer back Insert locking nuts into the drawer sides & Insert wooden dowels into the drawer sides . WARNING! Please wear goggles or protective eyewear whilst hammering dowels in place.
- Page 15 Assembly Instructions Step 16 Drawer assembly Attach drawer front to the drawer sides Use the allen key turn locking nuts clockwise to lock Cover locking nuts with caps b: Attach drawer base using screws & stabilizer IMPORTANT! Drawer MUST be “square” when base is attached.
-
Page 16: Hinge Adjustment
Assembly Instructions Step 17 Hanging flap Insert drawers to the cabinet. a: slot flap hinges onto ‘hinge plates’. b: Tighten screw shown to lock hinges in position. Adjust hinges so that gaps around the flap is even. Hinge adjustment Fix flap stay to the flap using screws Insert Shelf...
