Summary of Contents for GEZE ECdrive H
- Page 1 ECdrive H EN Pre-installation instructions Installation and service instructions 166539-00...
-
Page 2: Table Of Contents
ECdrive H Table of contents Symbols and means of representation ......................3 Product liability ................................3 Safety instructions ..............................3 Intended use........................................3 Safety instructions ......................................3 Safety conscious working ....................................4 Inspection of the installed system ................................4 Environmentally conscious working .................................4 Overview..................................5 Diagrams ..........................................5 Tools and aids ........................................5 Torques ..........................................5... -
Page 3: Symbols And Means Of Representation
à The country-specific laws and regulations are to be observed during safety-related tests. à GEZE shall not be liable for injuries or damage resulting from unauthorised modification of the system. à GEZE is not liable if products from other manufacturers are used with GEZE equipment. -
Page 4: Safety Conscious Working
Safety instructions ECdrive H à Observe the latest versions of guidelines, standards and country-specific regulations, in particular: à EN16005 “Power operated pedestrian doorsets - Safety in use - Requirements and test methods” à DIN 18650 “Building hardware - Powered pedestrian doors”... -
Page 5: Overview
ECdrive H Overview Overview 4. 1 Diagrams Drawing no. Type Name 70517-ep01 Installation diagram ECdrive H ISO-glass fitting 70511-9-0968 Wiring diagram DCU1/DCU1-2M 70722-9-0956 Additional wiring diagram DCU1/DCU1-2M for hospitals 70515-9-0982 Cable plan DCU1-NT-OP 70517-0-001 Drive drawing Drive system ECdrive H... -
Page 6: Pre-Installation
Pre-installation ECdrive H Pre-installation The up-to-date drive drawing is applicable for the pre-installation work to be carried out. All components must be identified and installed in accordance with the drive drawing. 5. 1 Prepare profiles For length and preparation of drive profiles, see drive drawing. -
Page 7: Connecting Transformer And Control Unit
ECdrive H Pre-installation Connecting transformer and control unit Note earthing connection! Do not mix up cores! Strip the three-core cable (2), attach insulated wire-end ferrules and connect to cable (1) at the transformer (see wiring diagram). Lay cable (2) to the control unit. -
Page 8: Installing Cable Holders
Pre-installation ECdrive H Lay rotary transducer cable (2) and motor connection cable (3) to the control unit. Insert the connector into the control unit. Do not plug rechargeable battery cable into the control unit yet. The rechargeable battery is not connected to the control until the production test and commissioning. -
Page 9: Final Work
ECdrive H Pre-installation Final work Check the position of the assembly groups against the drawing and check tightening torques. Perform production test. Attach stickers: à Identification plate (enter date of manufacture) à TÜV sticker Non-mounted parts or remaining assembly groups are prepared during the final assembly on site: à... -
Page 10: Installation
Installation ECdrive H Installation 6. 1 Preparations on site Check the preparations made on site by the customer to ensure proper installation: à Type and load capacity of the façade construction or base construction à Evenness of the installation surface à... - Page 11 ECdrive H Installation 6.2.2 Installing side plates Screw the side plates (2) to the side of the run- ning rail with 4.8 × 13 countersunk tapping screws (1). Screw the retaining block (4) to the side plates (2) on the inside with 4.8 × 13 countersunk tapping screws (3).
- Page 12 Installation ECdrive H 6.2.4 Suspending the door leaves ATTeNTION! Danger of injury by broken glass! Always mount the door leaf together with another person. Loosen fastening bolt (2). Dismantle roller holder (1) with rollers. Secure bracket support (3) to the top edge of the door using the square nut (4) and screw (5).
- Page 13 ECdrive H Installation 6.2.6 Aligning the door leaves Adjust the height of the door leaf with the screw (1). Tighten screws (2) after adjusting the door leaf. Install fastening bolt and adjust height. Gap between bolt and running rail = 0.5 mm (cor- responds to about 4 sheets of copy paper).
- Page 14 Installation ECdrive H Push driver (7) over holes in driving long arm (5) and driving short arm (6) and secure with 2 screws (M5) (8). Do not tighten the screws (8) yet. To adjust the main closing edge, slide the driver (7) in the oblong holes.
-
Page 15: Commissioning
ECdrive H Installation Commissioning 6.3. 1 Connecting the drive ATTeNTION! Danger of fatal injury due to electric shock! The electrical system (230 V) may only be connected and disconnected by a professional electrician. Perform the power connection and equipment earth conductor test in accordance with VDE 0100 Part 610. -
Page 16: Dismantling
Installation ECdrive H Swivel cover downwards and latch it into the stud screws (4). Place flat spring (5) over suspension clips (1): one in the middle and two on either side. Screw flat spring (5) with countersunk tap- ping screws (6). -
Page 17: Service And Maintenance
Tensioning the toothed belt See chapter 6.2.8. Maintenance check The mandatory maintenance work on the ECdrive H must be done by an expert: à at least once a year à when the service indicator on the programme switch lights up (see wiring diagram) Provide test documents and keep them up-to-date. -
Page 18: Troubleshooting
Troubleshooting ECdrive H Troubleshooting ATTeNTION! Danger of fatal injury due to electric shock! The electrical system (230 V) may only be connected and disconnected by a professional electrician. Perform the power connection and equipment earth conductor test in accordance with VDE 0100 Part 610. -
Page 19: Electrical Faults
ECdrive H Troubleshooting 8. 1 .3 Replacing brushes Secure door leaves against crashing down. Remove roller carriage. Pull brush (3) out of bracket support (1). Clean roller (2) and insert new brush. Reinstall roller carriage in reverse order. Electrical faults 8.2. - Page 20 E-Mail: danmark.se@geze.com Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk E-Mail: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH E-Mail: office-latvia@geze.com E-Mail: info@geze.es E-Mail: gezesea@geze.com.sg Niederlassung Süd-Ost www.geze.com www.geze.es...
