  • Page 1 EC drive H KIT EN Pre-installation instructions VP 190486-00...
  • Page 2: Table Of Contents

    ECdrive H KIT Contents Introduction................................3 Symbols and illustrations ....................................3 Revisions and validity .....................................3 Product liability .........................................3 Reference documents .....................................3 Fundamental safety precautions ........................4 Intended use........................................4 Safety notices ........................................4 Safety-conscious working .....................................5 Environmentally conscious working .................................5 Safety instructions related to transportation and storage .......................5 Qualification ........................................5 About this document .............................6 Overview..................................6...
  • Page 3: Introduction

    ECdrive H KIT Introduction Introduction 1. 1 Symbols and illustrations Warning notices In these instructions, warnings are used to warn against material damage and injuries. Always read and observe these warnings. Observe all measures marked with the warning symbol and warning word. Warning Warning word Meaning symbol...
  • Page 4: Fundamental Safety Precautions

    à in the installation variants / types of installation documented by GEZE à within the tested/approved area of application (climate / temperature / IP rating) Any other use is considered non-intended and will lead to the exclusion of all liability and warranty claims to GEZE. Safety notices à...
  • Page 5: Safety-Conscious Working

    à Storage temperatures under –30 °C and above +60 °C can result in damage to the product. à Protect the product against humidity. à Dry, well ventilated, closed, weather-proof and UV-protected rooms are suitable as storage areas. Qualification Installation of the GEZE sliding door drive may only be carried out by experts authorised by GEZE.
  • Page 6: About This Document

    About this document ECdrive H KIT About this document These instructions describe the pre-installation of the ECdrive H automatic sliding door drive. Overview 4. 1 Diagrams Drawing no. Type Name 70517-0-001 Drive drawing Drive ECdrive H 70517-ep01 Installation diagram ECdrive H ISO glass fittings 70517-2-0201 Component drawing Track made to measure for ECdrive H...
  • Page 7: Components And Assembly Groups

    ECdrive H KIT Overview Components and assembly groups These illustrations show the equipment of a standard drive in 2-leaf and 1-leaf version. The structure of the assembly groups can vary depending on the drive equipment or version. Precise details about positioning of the individual components can be found on the drive drawing (70517-0-001). 2-leaf 1-leaf, right hand slide to open 1-leaf, left hand slide to open...
  • Page 8: Pre-Installation

    Pre-installation ECdrive H KIT Pre-installation The most up-to-date diagram is applicable for performing the pre-installation work. All components must be identified and installed in accordance with the drive drawing. 5. 1 Cutting the track and cover to size à Track: Pos. 14 in assembly group list, Chapter 4.4 à...
  • Page 9: Installing Stop Buffers

    ECdrive H KIT Pre-installation Installing stop buffers Stop buffer: Pos. 13 in assembly group list, Chapter 4.4 Set stop buffers on the track on the left and right (1). Screw in the setscrews M6×6 (2) until they are in contact with the track. Do not tighten the setscrews.
  • Page 10: Installing The Drive Components

    Pre-installation ECdrive H KIT Installing the drive components The exact positioning of the components is given on the drive drawings. Illustrated: 1-leaf, ÖW = 700 mm Illustrated: 2-leaf, ÖW = 900 mm Legend: Length of drive ÖW Opening width Return pulley motor Return pulley Install the components with the screws provided in accordance with the drawing.
  • Page 11: Connecting Drive Motor And Control Unit

    ECdrive H KIT Pre-installation Connecting drive motor and control unit Route the rotary transducer cable (2) and motor connection cable (1) to the control unit (3). Insert the connector into the control unit (3). Checking the connection between rechargeable battery and control unit CAUTION! Danger of injury due to impact and crushing! When the rechargeable battery cable is plugged in, the door leaves can move unexpectedly.
  • Page 12: Installing Cable Holders

    Pre-installation ECdrive H KIT Installing cable holders IMPORTANT! Cables can be cut! Route cables in such a way that there are no cables near the moving parts. Secure the cable holder (1) on the track. Connecting transformer and control unit Make sure that cables are routed and secured in such a way that they do not become jammed when the cover is positioned and cannot come into contact with moving components.
  • Page 13 ECdrive H KIT Pre-installation Fix the cable holder DCU (5) to the control unit. Route the transformer cable (1) from the control unit through the cable holders (4) and (5) to the transformer. Fit the transformer cable (1) to the terminal (6) of the transformer.
  • Page 14: Mounting The Transformer Earthing

    Pre-installation ECdrive H KIT Mounting the transformer earthing Screw the device flat plug (2) to the rail (1) using the screw (3) (torque 4 Nm). Connect the earthing cable (4) from the trans- former to the device flat plug. 5. 1 0 Production test WARNING Risk of fatal injury due to electric shock! The electrical system (230/115 V) may only be connected and disconnected by a professional electrician.
  • Page 15: Preparation For Installation

    ECdrive H KIT Preparation for installation Preparation for installation During preparation for installation the drive unit is prepared for later installation. The current drive drawing is applicable for carrying out the installation work. All components must be identified and installed in accordance with the drive drawing.
