- Page 1 INSTRUCTION MANUAL Visit www.MaltaDynamics.com for the latest user instruction manual revision for this product offering as well as supporting documentation...
- Page 2 THE XSERIES MOBILE GRABBER INSTRUCTION MANUAL These instructions apply to the following model(s): X1000 Manual Revision Date: March 3, 2020 Please visit www.MaltaDynamics.com for the latest user instruction manual revision available for this product offering as well as supporting documentation. XSERIES Instruction Manual MaltaDynamics.com | 800-494-1840...
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL ....................4 WARNINGS & LIMITATIONS ..............5 Product LABEL ..................7 Conformity ....................8 GENERAL OPERATION & INITIAL SETUP ..........9 LIFITNG THE UNIT .................. 14 MAINTENANCE SCHEDULE ..............15 SAFETY INSTRUCTIONS ................. 15 INSPECTION .................... 16 INITIAL QUALITY INSPECTION ............... -
Page 4: General
GENERAL The Malta Dynamics Mobile Grabber is a mobile fall protection system. It is intended to provide an anchor point for working at height. The unit is comprised primarily of A36 steel and also includes (but not limited to) rubber, plastics, copper, concrete and hydraulic fluid. -
Page 5: Warnings & Limitations
The Malta Dynamics Mobile Grabber shall not be used outside of its limitations, or for any purposes other than that for which it is intended. It’s forbidden to use it as a lifting system. - Page 6 User must carry out a pre-use check of the equipment, to ensure that it is in a serviceable condition and operates correctly before each use. The pre-use check can be further explained under the topic INITIAL QUALITY INSPECTION. This section includes the features of the equipment that require the pre-use check, the method of checking, and the criteria against which the user can decide whether or not the equipment is defective The unit should only be moved with a tow vehicle, or other suitable moving device.
-
Page 7: Product Label
Product LABEL Visit www.MaltaDynamics.com for the latest user instruction manual revision for this product offering as well as supporting documentation... -
Page 8: Conformity
Name and address of the manufacturer Standard and type which the product is conform Pictogram which invites the user to read the instruction for use Conformity to the PPE regulation Number of user 2016/425 and number of notify body in charge of C2 control Model of product Month and year of... -
Page 9: General Operation & Initial Setup
GENERAL OPERATION & INITIAL SETUP Don a full body harness conforms to EN 361 according to the manufacturer’s instructions. WORKING AREA/USE: The maximum load that can be transmitted in service from the anchor device to the structure is 13kN in a downward direction. Furthermore, the minimum required strength is 13 kN. When using the unit, the walking/working surface being accessed by the user must be of a sufficient height as not to allow any part of a worker’s body to strike an object, or, the next lower level,... - Page 10 Before using the unit, be sure to read, understand, and follow the instructions that come with your system. Knowing how to use the system properly will greatly reduce the possibility of injury. 1. Using vehicle, position the unit as close as possible to working location (Unit may also be positioned with the optional Go! Friction Drive System).
- Page 11 4. Unhook any tie down straps. 5. Remove lock pin on the lower mast. 6. Turn the knob on the Hydraulic hand-pump to the “UP” position. 7. Attach the retractable fall arrest to the anchor point(s) with carabiner conforms to EN 362 and attach tag line(s) to retractable fall arrest.
- Page 12 8. While the mast is in the horizontal position, unpin the horizontal lock pin from the mast. 9. Pull out on the spring-loaded pin to the unlocked position (Located underside of the mast). 10. Once lock pins are removed, slide the mast out to the desired height and replace the horizontal lock pin.
- Page 13 LOCATION: The area where the system is used must be no less capable of supporting twice the weight of the system and the loads applied by the system in event of a fall. SYSTEM CAPACITY FOR X1000: The maximum number of users per unit is 2 . Only 1 user per individual anchor point is permitted.
-
Page 14: Lifitng The Unit
LIFITNG THE UNIT CRANE TRANSFER: This unit comes with lifting lugs which should only be used for lifting purposes. It is the responsibility of the owner to have a lifting plan in place before attempting to lift the unit. Extreme caution must be taken at all times and the plan shall include the use of a spreader bar. -
Page 15: Maintenance Schedule
12 months. All inquiries should be made to Malta Dynamics either by means of phone, fax, or e-mail. Malta Dynamics shall not be held responsible for injuries the user may receive from a fall if the system or any PPE is used outside of the prescribed scope or any Industrial Code of Practice Visit www.MaltaDynamics.com for the latest user instruction manual... -
Page 16: Inspection
12 months in strict compliance with the operating procedures of MALTA DYNAMICS LLd because the safety of the user is linked to the maintenance of efficiency and resistance of the equipment. - Page 17 Next Inspection Inspector (name Pass Fail (remarks) inspection date and signature) date Begin at the front of the machine, inspecting wiring for Ensure that the leveling jacks show no sign of wear or cracks or cuts. Ensure the 7-pin plug is in working order, damage.
-
Page 18: Initial Quality Inspection
INITIAL QUALITY INSPECTION (Use this form for the first inspection after receipt of system) Inspector: _______________________________ Purchase Date (mm/dd/yyyy): ______________________________ System Serial No: ____________________________________ Model Number: _______________________________ Year of Manufacture Date (yyyy): _____________________ Inspection Date (mm/dd/yyyy): _____________________________ Date of First Use (mm/dd/yyyy): ____________________________ INSPECTION ITEM PASS FAIL... -
Page 19: Limited Warranty
Malta Dynamics, LLC but manufactured by another, bears only the warranty given by such other manufacturer (Malta Dynamics, LLC agrees to furnish free of charge a written description of problem or cause). Warranty is voided by product abuse, alterations, use of equipment in applications for which it was not intended, use of non-manufacturer parts, or failure to follow documented service instructions. -
Page 20: Warranty Registration Form
Other Please complete this warranty registration card and return via mail, fax or email within 30 days of purchase to validate your manufacturer’s warranty for all Malta Dynamics products. Warranty provisions of this machine are handled directly through the manufacturer. -
Page 21: Eu Declaration Of Conformity
EU Declaration of Conformity Object of Declaration: X1000 Malta Dynamics Mobile Grabber Brand Name: Malta Dynamics Manufacturer: Malta Dynamics, LLC. Address: 210 13 Street Malta, Ohio 43758 This declaration of conformity is under the sole responsibility of the manufacturer: Malta Dynamics, LLC. - Page 22 800-494-1840 MaltaDynamics.com 210 13th Street Malta, OH 43758 USA XSERIES Instruction Manual MaltaDynamics.com | 800-494-1840...
