OPERATION AND INSTRUCTION MANUAL
WIRE ANCHOR SLINGS
Model: A6205, A6206
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
V2.4-B
Advertisement
Table of Contents
Related Manuals for Malta Dynamics A6205
Summary of Contents for Malta Dynamics A6205
- Page 1 OPERATION AND INSTRUCTION MANUAL WIRE ANCHOR SLINGS Model: A6205, A6206 WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
-
Page 2: Use Instructions
PURPOSE The A6205 and A6206 are anchorage connectors designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”... - Page 3 Model: A6205 or A6206 1.25” Tensile Strength (UTS): 5,000-lbf (22kN) Working load (WLL): 1,000-lbs (454kg) Max Capacity: 310-lbs (140kg) Length: Variable Materials: Aircraft Cable, Polyurethane, Zinc Plated Copper, Zinc Plated Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7(11), OSHA 1910.66, OSHA 1926.502...
- Page 4 CONFIGURATIONS BASKET ANCHOR VERTICAL CONFIGURATION: CONFIGURATION: “STRUCTURAL” ANCHOR POINT WARNING: Do not loop around sharp edges or structural members that could lessen structural integrity of the anchorage connector. Only make compatible connections! Due to the risk of improper loading, wire sling terminations must not be connected to each other by a single carabiner or snaphook.
-
Page 5: Work Surface
*The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). (ANCHOR POINT) WORK SURFACE *The structure the anchorage is attached to must be able to support 5,000-lbf (22kN). -
Page 6: Maintenance, Cleaning And Storage
MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with com- pressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product. - Page 7 Notes...
- Page 8 Malta Dynamics. Malta Dynamics shall be the sole judge of product condition and warranty options. This warranty applies only to original purchaser and is the only warranty applicable to this product.
