OPERATION AND INSTRUCTION MANUAL CHOKER ANCHOR SLINGS Model: A6203 IMPORTANT!!! ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST BE PROPERLY INSTRUCTED ON HOW TO USE THIS DEVICE.
PURPOSE The A6203 is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
Page 4
CONFIGURATIONS BASKET ANCHOR VERTICAL CHOKER ANCHOR CONFIGURATION: CONFIGURATION: CONFIGUATION: “STRUCTURAL” “STRUCTURAL” ANCHOR POINT ANCHOR POINT LOAD WARNING: THIS CONFIGURATION IS NOT APPROVED FOR FALL WARNING: Do not loop around sharp PROTECTION! edges or structural members that could NOT ANSI RATED! lessen structural integrity of the anchorage ONLY 2500-lbf connector.
*The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). (ANCHOR POINT) WORK SURFACE *The structure the anchorage is attached to must be able to support 5,000-lbf (22kN).
MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with com- pressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
Page 8
Malta Dynamics. Malta Dynamics shall be the sole judge of product condition and warranty options. This warranty applies only to original purchaser and is the only warranty applicable to this product.
