- Page 1 INSTRUCTION MANUAL...
- Page 2 THE MALTA DYNAMICS MOBILE GRABBER INSTRUCTION MANUAL These instructions apply to the following model(s): X1240, X1250 & X1260 Manual Revision Date: 16 August 2021 Please visit www.MaltaDynamics.com for the latest user instruction manual revision available for this product offering as well as supporting documentation...
- Page 3 X1 25 0 Weight: Tow Weight: 00 lbs. (approx.) 6100 lbs. (approx.) Length: 15’-6” Tow Length: 15’-6” Width: 6’-0” Tow Width: 6’-0” Height: 8’-5” Tow Height: 8’-5” iver: 2-5/16” Receiver: 2-5/16” 7 Blade RV Plug: 7 Blade RV es: Electric Brakes: Electric 15'-6"...
-
Page 4: Table Of Contents
TABLE OF CONTENTS General ---------------------------------------------------------------------------------------5 Training ---------------------------------------------------------------------------------------5 Training Topics-----------------------------------------------------------------------------5-6 Under Penalty of Law ---------------------------------------------------------------------6 Warnings & Limitations ---------------------------------------------------------------7-9 Towing and Moving ------------------------------------------------------------------------9 Lifting the Unit ------------------------------------------------------------------------10-12 Initial Setup & Operation -----------------------------------------------------------12-14 Wireless XSERIES Remote -------------------------------------------------------------14 Maintenance Schedule -----------------------------------------------------------------15 Fluids Used Within the System---------------------------------------------------------16 Deep Cycle Battery Maintenance -----------------------------------------------16-17 Mast Syncing -------------------------------------------------------------------------17-18 Burnishing Breaks --------------------------------------------------------------------18-19... -
Page 5: General
900lbs or less. This fall arrest system meets the needs of a construction and industrial worker’s safety requirements. The Malta Dynamics Mobile Grabber is comprised primarily of A36 steel but also includes but not limited to rubber, plastics, copper, concrete, hydraulic fluid, and battery components. -
Page 6: Under Penalty Of Law
The instructions are not to be removed except by the user of this system. Current instructions must always be available to any potential user. If you have any difficulty or experience any problems with Malta Dynamics systems or need assistance with the instruction: contact Malta Dynamics for assistance. -
Page 7: Warnings & Limitations
3 workers in any combination of Fall Arrest. The X1260 is designed for up to 5 workers. Each anchor point provided is rated for a single user up to 310lbs (including clothing, tools, etc.). The Malta Dynamics Mobile Grabber Fall Protection System is a mobile engineered anchorage solution designed to protect workers from fall hazards. - Page 8 Never use fall protection equipment for towing or hoisting. Do not increase the surface area of the platform or load. Increasing the area exposed to the wind will decrease machine stability. Inspect for dangers that may arise by the use of combinations of items and equipment in which the safe function of any one item is affected by or interferes with the safe function or another.
-
Page 9: Towing And Moving
Use only approved Malta Dynamics hardware and fasteners with this product. Do not attempt to move the system while workers are attached. The Malta Dynamics Mobile Grabber should always be placed on level surfaces. Main axle wheels must always be chocked unless unit is raised on outrigger jacks or if the unit is being moved. -
Page 10: Lifting The Unit
LIFTING THE UNIT CRANE TRANSFER : This unit comes with lifting lugs which should only be used for lifting purposes. It is the responsibility of the owner to have a lifting plan in place before attempting to lift the unit. Extreme caution must be taken at all times and the plan shall include the use of a spreader bar. - Page 11 SURFACE GRADE: The Malta Dynamics Mobile Grabber is designed for use on surfaces that allow the unit to be leveled within 2° horizontal and vertical to grade. Warning: Do not use on surfaces that do not allow the unit to be leveled within 2°...
-
Page 12: Initial Setup & Operation
Each anchor point provided is rated for a single user up to 310lbs. Caution must be taken when using self-retracting devices near moving machinery, electrical hazards, sharp edges, or abrasive surfaces. Contact with these elements may cause equipment failure, personal injury, or death. - Page 13 9. Use the attached tagline to lower SRD connector for use. Once attached, the system is ready to use. Follow any and all directions while attached to the Malta Dynamics Mobile Grabber. Visit www.MaltaDynamics.com for the latest user instruction manual...
- Page 14 XSERIES WIRELESS REMOTE WIRELESS REMOTE PAIRING INSTRUCTIONS: 1. Make sure unit power is in the off position. 2. Hold power button on the remote for 10-15 seconds. The green light on the remote will then begin to flash. 3. Turn the machine power to the on postion 4.
-
Page 15: Maintenance Schedule
MAINTENANCE SCHEDULE Malta Dynamics Mobile Grabber Maintenance & Inspection Schedule Annual Every Use Monthly (Competent (By Authorized (By Authorized Item to Inspect Person Other User) User) than End User) Tire Pressure Brake System Bettery Check Grease Coupler Labels Main Power Disconnect... -
Page 16: Fluids Used Within The System
FLUIDS USED WITHIN THE SYSTEM HYDRAULIC FLUID Standard-Mobile DTIO Excell22 Cold Weather- Schaffer #288 ISO 32 Synthetic Fill the hydraulic fluid to the full mark on the side glass located on the front of the hydraulic tank. The hydrualic fluid should be checked with the mast stowed. BATTERY Use only distilled or treated water that does not exceed 200 T.D.S (total dissolved solids... -
Page 17: Mast Syncing
million). Particular care should be taken to avoid metallic contamination (iron). 7. For best battery life, batteries should not be discharged below 80%of their rated capacity. 8. Avoid charging at temperatures above 120 degrees F or ambient, whichever is higher. 9. -
Page 18: Burnishing Breaks
The motor will sound different; this is perfectly fine. 3. Continue these bursts until unit is fully deployed. 4. The mast is now synced. Re-sync while compact: 1. Lower mast to full compact height. 2. Press the same button to lower unit and hold for 5 second bursts. The motor will sound different;... -
Page 19: Safety Instructions
You must be properly trained prior to using this equipment. All inquiries should be made to Malta Dynamics either by means of phone, fax, WARNING or e-mail. Malta Dynamics shall not be held responsible for injuries the user may receive from a fall if the system or any PPE is used outside of the prescribed scope or any Industrial Code of Practice. -
Page 20: Inspection
INSPECTION Inspection frequency: All systems shall be inspected visually by the user prior to each use. The unit shall be inspected by a competent person other than the end user at a minimum of once a year. Detailed inspection records shall be kept. An inspection chart is provided in the owner’s manual attached to the system for your convenience. - Page 21 12. Make sure that all labels are present and legible. 13. If ANY part of this inspection does not pass, mark machine with DO NOT USE tag and contact your authorized Malta Dynamics Mobile Grabber dealer. Visit www.MaltaDynamics.com for the latest user instruction manual...
-
Page 22: Initial Quality Inspection
INITIAL QUALITY INSPECTION (Use this form for the first inspection after receipt of system) Purchase Date (mm/dd/yy): _________________________________ System Serial No: ________________________________________ INSPECTION ITEM PASS FAIL Physical Damage to Body Damaged, loose, corroded, or missing hardware or connectors Check anchorage points are secured (mounting nuts tight) and inspect the eyes for distortion or cracks Check all bolts on mast are in place... -
Page 23: Limited Warranty
The foregoing shall be the exclusive remedy of the buyer and the exclusive liability of Malta Dynamics, LLC. Our warranty excludes normal replaceable wear items, i.e. gaskets, wear parts, seals, O-rings, belts, drive chains, clutches, etc. -
Page 24: Warranty Registration Card
WARRANTY REGISTRATION FORM Fax Warranty Registration Form to 740-586-0772 Malta Dynamics Mobile Grabber Warranty Registration Contact: Company Name: Address: City: State: Zip: Phone: ( Fax: ( Email: Purchased From: Purchase Date: Serial No: Type of Industry: Rental Construction Masonry Other Please complete this warranty registration card and return via mail, fax or email within 30 days of purchase to validate your manufacturer’s warranty for all Malta...
