Malta Dynamics A6104 Quick Start Manual

Easy slider i-beam anchor adjustable from 12”-30”

Advertisement

Quick Links

EASY SLIDER
I-BEAM ANCHOR
ADJUSTABLE FROM 12"-30"
Model # A6104
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 8,312,966 / US 8,353,653
V2.6-A

Advertisement

Table of Contents
loading

Summary of Contents for Malta Dynamics A6104

  • Page 1 EASY SLIDER I-BEAM ANCHOR ADJUSTABLE FROM 12”-30” Model # A6104 WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
  • Page 2 PURPOSE The A6104 is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
  • Page 3: Component Materials

    PERFORMANCE: REGULATORY COMPLIANCE: Static Tensile Strength: 5000-lbf (22kN) ANSI Z359.18 Type A, ANSI Z359.7(11), Maximum Capacity: One worker with max OSHA 1926.502, OSHA 1910.66, weight of 310-lbs when used as a single point anchorage connector for personal fall arrest or restraint system COMPONENT MATERIALS: DIMENSIONS: Aluminum: Cross Bar...
  • Page 4 LOADING CONDITIONS DIAGRAM Placement at or below a user’s working height requires integration of a compatible ANSI Z359.1 shock-absorbing lanyard that does not allow the user to extend more than 6 feet (in any direction) from the anchorage connector before the shock absorber is activated. The beam anchor must be attached to the I-beam flange facing the user (top flange if above, bottom flange if below, etc.).
  • Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). (ANCHOR POINT) WORK SURFACE Inspect retaining bushing for wear or damage.
  • Page 6: Warning Label Locations

    WARNING LABEL LOCATIONS BREAKING STRENGTH: 5000 lbf (22.2 kN) MFG: MM/YYYY WARNING: All persons using this equipment must read, understand and follow all instructions. Failure to do so could result in serious injury or death. Compliance: OSHA 1926.502, OSHA 1910.66, ANSI Z359.18 Type A, ANZI Z359.7(11) WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS.
  • Page 7: Maintenance, Cleaning And Storage

    MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
  • Page 8 LIMITED REMEDY: Upon notice in writing, Malta Dynamics will repair or replace all defective items at Malta Dynamics’s sole discretion. Malta Dynamics reserves the right to require that the defective item be returned to its plant for inspection before determining the appropriate course action.
