Full Body Harness Instruction Manual
FULL BODY HARNESS - INSTRUCTION MANUAL
THESE INSTUCTIONS APPLY TO THE FOLLOWING MODEL(S):
B2000
B2001
B2100
B2101
B2105
B2106
This manual must be read and understood in its entirety and used as part of your fall protection training
program as required by OSHA 1926 and State and local regulatory agencies. This instruction manual is
intended to meet industry standards required by and ANSI Z359.2007 and should be used as part of an
Employee Fall Safety training program as required by OSHA. User must read and fully understand the
limitations and proper use of the equipment, and be properly trained by employer prior to use per OSHA
29 CFR 1910.66, 29 CFR 1926.503, and applicable local standards.
User Instruction Manual
NOTE: This
User Instruction Manuals
before using equipment.
1
B2002
B2003
B2012
B2013
is not to be removed except by the user of this equipment. Current
must always be available to the user. Read and understand these instructions
Do not discard these instructions.
Mis
ail
imit ion
h
p
i
,
w w
ing , in
his
ip
h.
i
p rvi
MaltaDynamics.com
800-494-1840
405 Watertown Road, Waterford, OH 45786
ion
m
in
io
i
b
p
.
0120
EN 360:2002
1
Advertisement
Table of Contents
Related Manuals for Malta Dynamics B2000
Summary of Contents for Malta Dynamics B2000
- Page 1 Full Body Harness Instruction Manual FULL BODY HARNESS - INSTRUCTION MANUAL THESE INSTUCTIONS APPLY TO THE FOLLOWING MODEL(S): B2000 B2001 B2002 B2003 B2100 B2101 B2012 B2013 B2105 B2106 MaltaDynamics.com 800-494-1840 405 Watertown Road, Waterford, OH 45786 0120 EN 360:2002 This manual must be read and understood in its entirety and used as part of your fall protection training program as required by OSHA 1926 and State and local regulatory agencies.
-
Page 2: Materials And Construction
Galvanized Steel Purpose Malta Dynamics Full Body Harnesses are Class 3 full body harnesses designed for an array of full- body applications. Such full body harnesses are the only form of body wear acceptable for fall arrest. Full-body harnesses may also be used for positioning, travel restraint and rescue. - Page 3 Full Body Harness Instruction Manual Instructions for Use • Do not alter or intentionally misuse this equipment. WARNING: • Personal Fall Arrest System (PFAS) MUST limit the average arrest force to 900 lbs. (4kN) or less. • Employees shall be trained in accordance with the requirements of OSHA 29 CFR 1910.66 in the safe use of the system and its components before using a PFAS.
-
Page 4: Limitations For Use
• Part # B2000, B2001, B2002, B2003, B2100, B2101, B2102, and B2103 are designed for a single user with combined weight - including clothing, tools, etc. - within weight capacity range 130 lbs. - Page 5 Full Body Harness Instruction Manual hooks should not be connected to standard size D-rings or similar objects, as such use will result in a load on the gate if the hook or D-ring twists or rotates. Large throat snap hooks are designed for use on structural elements such as rebar or cross members that are not shaped in such a way that they may capture the gate of the hook.
- Page 6 Full Body Harness Instruction Manual Performance Each Malta Dynamics Full Body Harness has a minimum tensile breaking strength of 5,000 lbs. (22.2 kN) when statically tested in accordance with the requirements of the ANSI Z359.1:2007 standard. Malta Dynamics Full Body Harness stretch is less than 8 inches.
- Page 7 Full Body Harness Instruction Manual • Rescue: The structure to which rescue system is attached must sustain static loads applied in the directions permitted by the work positioning system of at least 3,000 lbs., or five times the potential impact load, whichever is greater. See OSHA1926.502. When more than one work positioning system is attached to an anchorage, the strengths stated above must be multiplied by the number of work positioning systems attached to the anchorage.
- Page 8 Full Body Harness Instruction Manual If there is a risk of a fall or if the anchorage point is below the attachment points on the harness, it is essential to use a lanyard with an energy absorber. Before using a shock absorbing lanyard, ensure that there is sufficient fall clearance below the user to prevent any collision with the structure or the ground.
- Page 9 In the event of a fall, simply lift up your legs to transfer weight to the sub-pelvic strap. Parts of Full Body Harness All Malta Dynamics Harness models (Illustration 9a): Illustration 9a: Parts of Harness 1. Shoulder Straps 2. Chest Strap 3.
- Page 10 Full Body Harness Instruction Manual Some harness models feature belts and/or the parts (Illustration 9b): Illustration 9b: Additional Features Shoulder Padding B. Waist Belt C. Hip D-Ring/Positioning D-Ring (used in pairs only) Training Employers are responsible for providing training to any employee who may be exposed to fall hazards in order to enable the employee to recognize and reduce fall hazards.
-
Page 11: Cleaning And Maintenance
Avoid storing in direct light to prevent UV degradation. Maintenance Do not attempt to disassemble the harness. Only Malta Dynamics or entities authorized in writing by Malta Dynamics shall make repairs, authorized maintenance or alterations to the equipment. -
Page 12: Product Labels
Full Body Harness Instruction Manual Product Labels The following labelling is affixed to product and must not be removed: with Pass-Thru Leg Buckles ANSI Z359.11-2014 A10.32-2012 1 Worker WORKING LOAD RANGE: 800-494-1840 405 Watertown Road, Waterford, OH 45786... - Page 13 Full Body Harness Instruction Manual Product Labels The following labelling is affixed to product and must not be removed:...
- Page 14 Full Body Harness Instruction Manual Product Labels The following labelling is affixed to product and must not be removed:...
- Page 15 Full Body Harness Instruction Manual Inspection Log Date of Manufacture: Model Name/#: Serial #: Date of First Use: INSPECTION DATE ITEMS NOTED CORRECTIVE ACTION APPROVED BY 800-494-1840 405 Watertown Road, Waterford, OH 45786...
-
Page 16: Warranty
Warranty does not cover equipment damage resulting from wear, abuse, damage in transit, failure to maintain the product or other damage beyond the control of Malta Dynamics. Malta Dynamics shall be the sole judge of product condition and warranty options. This warranty applies only to original purchaser and is the only warranty applicable to this product. - Page 17 Full Body Harness Instruction Manual APPENDIX ____________________________________________________________________________________ Annex A – Normative Note: This information from the Z359.11 standard is required to be included in the instruction manual for the end user. ANSI/ASSE Z359 Requirements for Proper Use and Maintenance of Full Body Harnesses Note: The following are general requirements and information provided by ANSI/ASSE Z359, the Manufacturer of this equipment, may impose more stringent restrictions on the use of the products they manufacture, see the Manufacturer’s instructions.
- Page 18 Full Body Harness Instruction Manual 6. Full Body Harness (FBH) Stretch, the amount the FBH component of a personal fall arrest system will stretch and deform during a fall, can contribute to the overall elongation of the system in stopping a fall. It is important to include the increase in fall distance created by FBH Stretch, as well as the FBH connector length, the settling of the user’s body in the FBH and all other contributing factors when calculating total clearance required for a particular fall arrest system.
- Page 19 Full Body Harness Instruction Manual chest strap to slide up and possibly choke the user during a fall, extraction, suspension, etc. The competent person should consider Full Body Harness models with a fixed sternal attachment for these applications. 12. Frontal – The frontal attachment serves as a ladder climbing connection for guided type fall arresters where there is no chance to fall in a direction other than feet first, or may be used for work positioning.
-
Page 20: Inspection Log
Inspection Log Full Body Harness Instruction Manual Date of Manufacture: Model Name/#: equipment shall be inspected by the user before each use and, additionally, by a competent person, other than the user, at interval of no more than one year for: Serial #: Date of First Use: •...
