Technical data

Maximum flow rate
Pump type
Operating pressure,
maximum
Permissible suction pressure
at suction port
Permitted viscosity range
Permitted fluid temperature
range
Permitted ambient
temperature range
Sealing material
IP class
Noise level
Connector cable, length
Signal cable, length
Length of hoses
Suction hose
Pressure hose
Weight when empty
OF7S / OF7K
BeWa OF7 3430048e en-us 2016-04-28.doc
OF7S10 OF7S90
15 l/min 5 ... 15 l/min
Vane pump Vane pump
3,5 bar / 4,5 bar /
50 psi 65 psi
± 0,4 bar / ± 0,4 bar /
± 5,8 psi ± 5,8 psi
5 ... 350 15 ... 1000
mm²/s mm²/s
0 ... 80 °C / 0 ... 80 °C /
32 ... 176 °F 32 ... 176 °F
-20 ... 40 °C / -20 ... 40 °C /
-4 ... 104 °F -4 ... 104 °F
NBR NBR
IP 54 IP 54
65 dBA max. 65 dBA max.
2,8 m 10 m
- -
2.5 m 2.5 m
DN 20 DN 20
with lance with lance
DN 16 DN 16
with lance with lance
≈ 12.5 kg ≈ 18.0 kg
en(us)
Technical data
OF7K
10 l/min
Vane pump
3,5 bar /
50 psi
± 0,4 bar /
± 5,8 psi
5 ... 350
mm²/s
0 ... 80 °C /
32 ... 176 °F
-20 ... 40 °C /
-4 ... 104 °F
NBR
IP 54
65 dBA max.
10 / 15 m
10 m / 15 m /
without
(depending
on how unit is
ordered)
2.5 m
DN 20
with lance
DN 16
with lance
≈ 12.5 kg
