Modine Manufacturing ECO ICE Series Technical Manual page 8

Manufacturing and dimensional features WD versions (water defrost)
Model ICE ø 450
Fan motors n.
Connection WD n. x ø
GAS
Dimensions A
(mm) B
C
D
E
Recommendations for a proper access to model
Access
1. Dismantle drain connection and position as
to avoid hampering with the drip tray.
2. Remove rear baffle and unfasten front and
rear drip tray knobs, then carefully bring to
position shown in sketch.
Important before opening drip tray check
that it is free from ice build-up.
3. Unfasten screws "B" to remove side panels.
4. Unfasten screws "C" to remove fan motors; if
it is necessary to remove the fan shrouds
unfasten screws "D".
Remounting
1. Fasten the fan shrouds with screws "D" and
the motors with screws "C".
2. Fasten side panels with srews "B".
3. Reposition drip tray; before clamping knobs
"A" reposition the baffle.
4. Reconnect the drain connection.
6
www.modine.com
D D
A A
1 2 3
1 x 1 1 x 1 1 x 1 2 x 1
1/4 1/4 1/4
- - - 1050
- - - 1700
- - - 1050
626 1050 1475
626 1050 1475
Fan motor
B B
Model ICE ø 560/630
4 Fan motors n.
Connec. WD n. x ø
1/4
Dimensions
(mm)
-
-
C Fan shroud
D
E E
C C
1 2 3
1 x 1 1 x 1 1 x 1
GAS 1/4 1/4 1/4
A - - -
B - - -
C - - -
D 750 1300 1851
E 750 1300 1851
Side panel
Drain connection
Drip tray
A
4 5
2 x 1 2 x 1
1/4 1/4
1295 1295
2210 2760
1313 1863
- -
- -
B
Baffle
