Modine Manufacturing ECO ICE Series Technical Manual page 6

Model with ø 560 mm fan motor
186,5
B
F
A
Modell ICE ø 560
Dimensions A
(mm) B
H
Coil entrata
connections (mm)
uscita
Drain connection
GAS
"WD" def. connection
GAS
Max weight kg
Use thermostatic valve with external pressure equalizer.
Positioning of electric heaters
51A / 52A / 53A / 54A
06 08 10 12
RBA - High power electric heaters in coil
RBB - Low power electric heaters in coil
RSA - High power electric heaters on drip tray
RSB - Low power electric heaters on drip tray
4
www.modine.com
186,5
H
51A 51B 52A
06 08 10 12 06 08 10 12 06 08 10 12 06 08 10 12 06 08 10 12 06 08 10 12 06 08 10 12 06 08 10 12
1550 1550 2650
1130 1130 2230
- - -
22 22 28
42 42 54
2 2 3
1 1 1
1/4 1/4 1/4
89 107 170
1070
925
100
80
746
900 min.
995
52B 52D 53A
2650 2650 3750
2230 2230 3330
- - -
28 35 28
54 54 54
3 3 3
1 1 1
1/4 1/4 1/4
205 266 240
52B / 53B / 54B
06 08 10 12
F
249
53B 53D 54A
06 08 10 12 06 08 10 12 06 08 10 12
3750 3750 4850
3330 3330 4430
- - 2228
35 35 35
54 54 54
3 3 3
1 1 2 x 1
1/4 1/4 1/4
283 368 328
52D / 53D / 54D
06 08 10 12
54B 54D
4850 4850
4430 4430
2228 2228
35 2 x 35
54 2 x 54
3 3
2 x 1 2 x 1
1/4 1/4
385 498
